Transgene-free Genome Editing in Grapevine

Materials and reagents

Biological materials

1. In vitro–grown grapevine plants

2. Inflorescences of open field plants or greenhouse-grown cuttings

Reagents

1. Enzymes

a. Cellulase R10 (Duchefa Biochemie, catalog number: C8001)

b. Macerozyme R10 (Duchefa Biochemie, catalog number: M8002)

c. Pectolyase Y-23 (Duchefa Biochemie, catalog number: P8004)

2. Fluorophores

a. Fluorescein diacetate (FDA) (Sigma-Aldrich, catalog number: 343209)

b. Fluorescent brightener 28 disodium salt (Chemcruz, catalog number: sc-218504)

3. Gelling agents

a. Agar TC (PhytoTech Labs, catalog number: A296)

b. Phytagel (Sigma-Aldrich, catalog number: P8169)

c. Gelrite (Duchefa Biochemie, catalog number: G1101)

4. Growth regulators

a. 6-Benzylaminopurine (6-BAP) (Duchefa Biochemie, catalog number: B0904)

b. 2,4-Dichlorophenoxyacetic acid (2,4-D) (Duchefa Biochemie, catalog number: D0911)

c. α-Naphthalene acetic acid (NAA) (Duchefa Biochemie, catalog number: N0903)

d. β-Naphthoxyacetic acid (NOA) (Duchefa Biochemie, catalog number: N0912)

5. Kit

a. Qubit^TM RNA BR Assay kit, 500 assays (Invitrogen, Thermo Fisher Scientific, catalog number: Q10211)

b. GeneArt Precision gRNA Synthesis kit (Invitrogen, Thermo Fisher Scientific, catalog number: A29377)

6. Proteins

a. TrueCut ^TM Cas9 protein v2 (Invitrogen, Thermo Fisher Scientific, catalog number: A36499)

7. Salts and biochemicals

a. CaCl₂·2H₂O (Duchefa Biochemie, catalog number: C0504)

b. Ca(NO₃)₂·4H₂O (Duchefa Biochemie, catalog number: C0505)

c. KCl (Sigma-Aldrich, catalog number: 31219)

d. KH₂PO₄ (Duchefa Biochemie, catalog number: P0574)

e. KNO₃ (Duchefa Biochemie, catalog number: P0519)

f. K₂SO₄ (Duchefa Biochemie, catalog number: P0535)

g. MgCl₂·6H₂O (Duchefa Biochemie, catalog number: M0533)

h. MgSO₄·7H₂O (Duchefa Biochemie, catalog number: M0513)

i. NaCl (Duchefa Biochemie, catalog number: S0520)

j. NH₄NO₃ (Duchefa Biochemie, catalog number: A0501)

k. NH₄Cl (Duchefa Biochemie, catalog number: A0528)

l. CuSO₄·5H₂O (Duchefa Biochemie, catalog number: C0508)

m. FeNaEDTA (Duchefa Biochemie, catalog number: E0509)

n. FeSO₄·7H₂O (Duchefa Biochemie, catalog number: F0512)

o. H₃BO₃ (Duchefa Biochemie, catalog number: B0503)

p. MnSO·H₂O (Duchefa Biochemie, catalog number: M0514)

q. Na₂MO₄·2H₂O (Duchefa Biochemie, catalog number: S0525)

r. Na₂EDTA·2H₂O (Duchefa Biochemie, catalog number: E0511)

s. ZnSO₄·7H₂O (Duchefa Biochemie, catalog number: Z0526)

t. KI (Duchefa Biochemie, catalog number: P0518)

u. CoCl₂·6H₂O (Duchefa Biochemie, catalog number: C0507)

v. Sucrose (Duchefa Biochemie, catalog number: S0809)

w. D-Mannitol (Duchefa Biochemie, catalog number: M0803)

x. D-Glucose monohydrate (Duchefa Biochemie, catalog number: G0802)

y. Polyethylene glycol 4000 (PEG 4000) (Duchefa Biochemie, catalog number: P0804)

z. 2-(N-morpholino) ethane sulfonic acid (Duchefa Biochemie, catalog number: M1503)

aa. Biotin (Duchefa Biochemie, catalog number: B0603)

bb. Folic acid (Duchefa Biochemie, catalog number: F0608)

cc. Myo-inositol (Duchefa Biochemie, catalog number: I0609)

dd. Glycine (Duchefa Biochemie, catalog number: G0709)

ee. Nicotinic acid (Duchefa Biochemie, catalog number: N0611)

ff. Pyridoxine HCl (Duchefa Biochemie, catalog number: P0612)

gg. Thiamine HCl (Duchefa Biochemie, catalog number: T0614)

hh. D-pantothenate calcium (vitamin B5 calcium) (Duchefa Biochemie, catalog number: C0604)

ii. L-glutamic acid (Duchefa Biochemie, catalog number: G0707)

jj. L-phenylalanine (Duchefa Biochemie, catalog number: P0716)

kk. TopVision agarose (Thermo Scientific, Thermo Fisher Scientific, catalog number: R0491)

ll. 100 bp DNA ladder (Life Technologies, Thermo Fisher Scientific, catalog number: SM0241)

mm. Syber^® safe DNA gel stain (Invitrogen, Thermo Fisher Scientific, catalog number: S33102)

nn. TriTrack DNA loading dye 6× (Life Technologies, Thermo Fisher Scientific, catalog number: R1161)

oo. Acetocarmine staining (Sigma-Aldrich, catalog number: 280370)

pp. NaClO (Sigma-Aldrich, catalog number: 1056142500)

qq. Tween-20 (Sigma-Aldrich, catalog number: P1379)

8. Supplements

a. Casein hydrolysate (Duchefa Biochemie, catalog number: C1301)

b. Activated charcoal (Sigma-Aldrich, catalog number: 31616)

Solutions

1. Macronutrients

a. NN macronutrients 10× (see Recipes)

b. MS macronutrients 10× (see Recipes)

c. C2D macronutrients 10× (see Recipes)

2. Micronutrients

a. NN micronutrients 100× (see Recipes)

b. MS micronutrients 1,000× (without FeEDTA) (see Recipes)

c. MS micronutrients 100× (see Recipes)

d. C2D micronutrients 1,000× (see Recipes)

3. Hormones

a. 2,4-Dichlorophenoxyacetic acid 1,000 µM (see Recipes)

b. 6-Benzylaminopurine 1,000 µM (see Recipes)

c. 1-Naphthaleneacetic acid 1,000 µM (see Recipes)

d. β-Naphthoxyacetic acid 1,000 µM (see Recipes)

4. Vitamins

a. NN vitamins 500× (see Recipes)

b. MS vitamins 500× (see Recipes)

c. C2D vitamins 1,000× (see Recipes)

d. B5 vitamins 500× (see Recipes)

e. Vitamins mix C1 500× (see Recipes)

f. Vitamins T 1,000×: (see Recipes)

5. Amino acids

a. Amino acids mix 1,000× (see Recipes)

6. Chemicals

a. FeEDTA 200× (see Recipes)

b. KCl 500 mM (see Recipes)

c. 2-(N-morpholino) ethanesulfonic acid 100 mM, pH 5.7 (see Recipes)

d. CaCl₂·2H₂O 1 M (see Recipes)

e. MgCl₂·6H₂O 500 mM (see Recipes)

f. NaCl 1 M (see Recipes)

7. Organics

a. Mannitol 1 M (see Recipes)

b. Glucose 3 M (see Recipes)

8. Culture media for induction of embryogenic calli (see Recipes)

a. NB2 (culture medium for induction of embryogenic calli from in vitro leaves)

b. PIV (culture medium for induction of embryogenic calli from stamens and pistils)

c. MSII (culture medium for induction of embryogenic calli from stamens and pistils)

9. Culture medium for long-term maintenance of embryogenic calli (C1^P) (see Recipes)

10. Culture medium for somatic embryos full germination (see Recipes)

11. Culture media for somatic embryos shooting (see Recipes)

a. C2D

b. C2D4B

c. MG1

d. MG1–10B

12. Culture media for full plant development and rooting (see Recipes)

a. RIM

b. MSN

13. Culture media for protoplasts cultivation (see Recipes)

a. Solid culture medium

b. Liquid culture medium

14. Solution for protoplast isolation, purification, and transfection (see Recipes)

a. Digestion solution

b. Digestion solution without enzymes

c. Wash solution

d. W5 solution

e. MMG solution

f. PEG solution

Recipes

1. Macronutrients

a. NN macronutrients 10×: 2.2 g/L CaCl₂·2H₂O, 9.5 g/L KNO₃, 7.2 g/L NH₄NO₃, 1.85 g/L MgSO₄·7H₂O, 0.68 g/L KH₂PO₄

b. MS macronutrients 10×: 16.5 g/L of NH₄NO₃, 4.4 g/L of CaCl₂·2H₂O, 3.7 g/L of MgSO₄·7H₂O, 19.7 g/L of KNO₃ and 1.7 g/L of KH₂РО₄

c. C2D macronutrients 10×: 16.5 g/L NH₄NO₃, 19 g/L KNO₃, 3.7 g/L MgSO₄·7H₂O, 1.7 g/L KH₂PO₄, 7.1 g/L Ca(NO₃)₂·4H₂O, 0.28 g/L FeSO₄·7H₂O, 0.37 g/L Na₂EDTA

2. Micronutrients

a. NN micronutrients 100×: 2.5 mg/L CuSO₄·5H₂O, 3.67 g/L FeNaEDTA, 1 g/L H₃BO₃, 1.9 g/L MnSO₄·H₂O, 25 mg/L Na₂MoO₄·2H₂O, 1g/L ZnSO₄·7H₂O

b. MS micronutrients 1,000× (without FeEDTA): 6.2 g/L H₃BO₃, 16.9 g/L MnSO₄·H2O, 8.6 g/L ZnSO₄·7H₂O, 0.83 g/L KI, 0.25 g/L Na₂MoO₄·2H₂O, 25 mg/L CuSO₄·5H₂O, 25 mg/L CoCl₂·6H₂O

c. MS micronutrients 100×: 0.62 g/L H₃BO₃, 3.67 g/L FeNaEDTA, 1.69 g/L of MnSO₄·H₂O, 0.86 g/L ZnSO₄·7H₂O, 0.083 g/L of KI, 0.025 g/L Na₂MoO₄·2H₂O, 0.0025 g/L CuSO₄·5H₂O, 0.0025 g/L CoCl₂·6H₂O

d. C2D micronutrients 1,000×: 0.64 g/L MnSO₄·H₂O, 6.2 g/L H₃BO₃, 8.6 g/L ZnSO₄·7H₂O, 0.25 g/L Na₂MoO₄·2H₂O, 25 mg/L CuSO₄·5H₂O, 25 mg/L CoCl₂·6H₂O

3. Hormones

Note: All the following hormone powders are soluble in NaOH 1 M. It is important to add NaOH 1 M to the weighed powder before the addition of water.

a. 2,4-Dichlorophenoxyacetic acid 1,000 µM: 0,221 g/L of 2.4-dichlorophenoxyacetic acid

b. 6-Benzylaminopurine 1,000 µM: 0.2252 g/L of 6-benzylaminopurine

c. 1-Naphthaleneacetic acid 1,000 µM: 0.1862 g/L of 1-naphthaleneacetic acid

d. β-Naphthoxyacetic acid 1,000 µM: 0.2022 g/L of β-naphthoxyacetic acid

4.Vitamins

a. NN vitamins 500×: 25 mg/L biotin, 0.25 g/L folic acid, 1 g/L glycine, 50 g/L myo-Inositol, 2.5 g/L nicotinic acid, 0.25 g/L Pyridoxine HCl, 0.25 g/L thiamine HCl

b. MS vitamins 500×: 1 g/L glycine, 50 g/L myo-inositol, 0.25 g/L nicotinic acid, 0.25 g/L pyridoxine HCl, 0.05 g/L thiamine HCl

c. C2D vitamins 1,000×: 1 g/L thiamine HCl, 10 g/L myo-inositol, 1 g/L nicotinic acid, 1 g/L pyridoxine HCl

d. B5 vitamins 500×: 50 g/L myo-inositol, 5 g/L thiamine HCl, 0.5 g/L nicotinic acid, 0.5 g/L pyridoxine HCl

e. Vitamins mix C1 500×: 50 g/L of myo-inositol, 5 g/L of nicotinic acid, 5 g/L of thiamine-HCI, 0.5 g/L of pyridoxine-HCl, 0.5 g/L of calcium pantothenate, 0.005 g/L of biotin

f. Vitamins T 1,000×: 50 g/L myo-inositol, 1 g/L nicotinic acid, 1 g/L thiamine HCl, 1 g/L pyridoxine HC, 1 g/L calcium pantothenate, 0.01 g/L biotin.

5. Amino acids

a. Amino acids mix 1,000×: 100 g/L L-glutamic acid (monosodium salt), 10 g/L L-phenylalanine, 2 g/L glycine

6. Chemicals

a. FeEDTA 200×: 7.44 g/L of Na₂EDTA·2H₂O, 1.86 g/L of FeSO₄·7H₂O

b. KCl 500 mM: 37.775 g/L of KCL

c. 2-(N-morpholino) ethanesulfonic acid 100 mM, pH 5.7: 19.52 g/L of 2-(N-morpholino) ethanesulfonic acid.

Note: Adjust the pH of this solution to 5.7 with KOH 1 M

d. CaCl₂·2H₂O 1 M: 146.9 g/L of CaCl₂·2H₂O

e. MgCl₂·6H₂O 500 mM: 101.655 g/L of MgCl₂·6H₂O

f. NaCl 1 M: 58.44 g/L of NaCl

7. Organics

a. Mannitol 1 M: 182.17 g/L of D-mannitol

b. Glucose 3 M: 594.6 g/L of glucose

8. Culture media for induction of embryogenic calli

a. NB2 (culture medium for induction of embryogenic calli from in vitro leaves)

Component	Stock concentration	Final concentration	Quantity or Volume (1 L)
NN macronutrients	10×	1×	100 mL
NN micronutrients	100×	1×	10 mL
MS vitamins	500×	1×	2 mL
6-benzylaminopurine	1,000 μM	1.0 μM	1 mL
2,4-dichlorophenoxyacetic acid	1,000 μM	5.0 μM	5 mL
Myo-inositol	/	0.1 g/L	0.1 g
Sucrose	/	20 g/L	20 g
Adjust to final pH 6.0 with KOH 1 M
Agar TC	/	7 g/L	7 g

b. PIV (culture medium for induction of embryogenic calli from stamens and pistils)

Component	Stock concentration	Final concentration	Quantity or Volume (1 L)
NN macronutrients	10×	1×	100 mL
MS micronutrients	1,000×	1×	1 mL
FeEDTA	200×	1×	5 mL
B5 vitamins	500×	1×	2 mL
6-benzylaminopurine	1,000 μM	8.9 μM	8.9 mL
2,4-dichlorophenoxyacetic acid	1,000 μM	4.5 μM	4.5 mL
Sucrose		60 g/L	60 g
Adjust to final pH 5.7 with KOH 1 M
Phytagel	/	3 g/L	3 g

c. MSII (culture medium for induction of embryogenic calli from stamens and pistils)

Component	Stock concentration	Final concentration	Quantity or Volume (1 L)
MS macronutrients	10×	1×	100 mL
MS micronutrients	100×	1×	10 mL
MS vitamins	500×	1×	2 mL
β-naphthoxyacetic acid	1,000 μM	2.5 μM	2.5 mL
6-benzylaminopurine	1,000 μM	5 μM	5 mL
2,4-dichlorophenoxyacetic acid	1,000 μM	2.5 μM	2.5 mL
Myo-inositol	/	0.1 g/L	0.1 g
Sucrose	/	20 g/L	20 g
Adjust to final pH 6.0 with KOH 1 M
Agar TC	/	7 g/L	7 g

9. Culture medium for long-term maintenance of embryogenic calli (C1^P)

Component	Stock concentration	Final concentration	Quantity or Volume (1 L)
MS macronutrients	10×	1×	100 mL
MS micronutrients	1,000×	1×	1 mL
Vitamins C1	500×	1×	2 mL
AA mix	1,000×	1×	1 mL
Fe-EDTA	200×	1×	5 mL
2,4-dichlorophenoxyacetic acid	1,000 μM	5 μM	5 mL
6-benzylaminopurine	1,000 μM	1 μM	1 mL
Casein hydrolysate	/	1 g/L	1 g
Sucrose	/	30 g/L	30 g
Adjust to final pH 5.8 with KOH 1 M
Phytagel	/	5g/L	5 g

10. Culture medium for somatic embryos full germination

Component	Stock concentration	Final concentration	Quantity or Volume (1 L)
NN macronutrients	10×	1×	100 mL
NN micronutrients	100×	1×	10 mL
NN vitamins	500×	1×	2 mL
Sucrose	/	30 g/L	30 g
Adjust to final pH 5.8 with KOH 1 M
Gelrite	/	2 g/L	2 g

11. Culture media for somatic embryo shooting

a. C2D

Component	Stock concentration	Final concentration	Quantity or Volume (1 L)
C2D macronutrients	10×	1×	100 mL
C2D micronutrients	1,000×	1×	1 mL
C2D vitamins	1,000×	1×	1 mL
Sucrose	/	30 g/L	30 g
Adjust to final pH 5.8 with KOH 1 M
Agar TC	/	7 g/L	7 g

b. C2D4B

Component	Stock concentration	Final concentration	Quantity or Volume (1 L)
C2D macronutrients	10×	1×	100 mL
C2D micronutrients	1,000×	1×	1 mL
C2D vitamins	1,000×	1×	1 mL
6-benzylaminopurine	1,000 μM	4 μM	4 mL
Sucrose	/	30 g/L	30 g
Adjust to final pH 5.8 with KOH 1 M
Agar TC	/	7 g/L	7 g

c. MG1

Component	Stock concentration	Final concentration	Quantity or Volume (1 L)
NN macronutrients	10×	1×	100 mL
MS micronutrients	1,000×	1×	1 mL
Fe-EDTA	200×	1×	5 mL
B5 vitamins	500×	1×	2 mL
Sucrose	/	30 g/L	30 g
Adjust to final pH 5.8 with KOH 1 M
Agar TC	/	7 g/L	7 g
Activated charcoal	/	2.5 g/L	2.5 g

d. MG1-10B

Component	Stock concentration	Final concentration	Quantity or Volume (1 L)
NN macronutrients	10×	1×	100 mL
MS micronutrients	1,000×	1×	1 mL
Fe-EDTA	200×	1×	5 mL
B5 vitamins	500×	1×	2 mL
6-benzylaminopurine	1,000 μM	10 μM	10 mL
Sucrose	/	30 g/L	30 g
Adjust to final pH = 5.8 with KOH 1 M
Agar TC	/	7 g/L	7 g
Activated charcoal	/	2.5 g/L	2.5 g

12. Culture media for full plant development and rooting

a. RIM

Component	Stock concentration	Final concentration	Quantity or Volume (1 L)
MS macronutrients	10×	1×	100 mL
MS micronutrients	1,000×	1×	1 mL
Fe-EDTA	200×	1×	5 mL
Vitamins T	1,000×	1×	1 mL
1-naphthaleneacetic acid	1,000 μM	0.5 μM	500 μL
Sucrose	/	30 g/L	30 g
Adjust to final pH 6.0 with KOH 1 M
Agar TC	/	7 g/L	7 g

b. MSN

Component	Stock concentration	Final concentration	Quantity or Volume (1 L)
MS macronutrients	10×	1×	100 mL
MS micronutrients	100×	1×	10 mL
MS vitamins	500×	1×	2 mL
1-naphthaleneacetic acid	1,000 μM	0.5 μM	500 μL
Sucrose	/	30 g/L	30 g
Adjust to final pH 5.8 with KOH 1 M
Agar TC	/	7 g/L	7 g

13. Culture media for protoplast cultivation

a. Solid culture medium

Component	Stock concentration	Final concentration	Quantity or Volume (50 mL)
NN macronutrients	10×	1×	5 mL
NN micronutrients	100×	1×	500 μL
NN vitamins	500×	1×	100 μL
1-naphthaleneacetic acid	1,000 μM	10 μM	500 μL
6-benzylaminopurine	1,000 μM	2 μM	100 μL
Glucose	3 M	0.3 M	5 mL
Sucrose	/	30 g/L	1.50 g
Adjust to final pH 5.7 with KOH 1 M
Gelrite	/	2 g/L	0.1 g

b. Liquid culture medium

Component	Stock concentration	Final concentration	Quantity or Volume (50 mL)
NN macronutrients	10×	1×	5 mL
NN micronutrients	100×	1×	500 μL
NN vitamins	500×	1×	100 μL
1-Naphthaleneacetic acid	1,000 μM	10 μM	500 μL
6-benzylaminopurine	1,000 μM	2 μM	100 μL
Glucose	3 M	0.3 M	5 mL
Sucrose	/	30 g/L	1.50 g
Adjust to final pH 5.7 with KOH 1 M
Activated charcoal	/	3 g/L	0.15 g

14. Solution for protoplast isolation, purification, and transfection

a. Digestion solution

Component	Stock concentration	Final concentration	Quantity or Volume (20 mL)
Cellulase R10	/	2% w/v	0.4g
Macerozyme R10	/	1 % w/v	0.2 g
Pectolyase Y-23	/	0.05 % w/v	0.01 g
CaCl2·2H2O	1 M	10 mM	200 μL
2-(N-morpholino) ethanesulfonic acid, pH 5.7	100 mM	5 mM	1 mL
Mannitol	1 M	0.5 M	10 mL
Adjust to final pH 5.7 with KOH 1 M

b. Digestion solution without enzymes

Component	Stock concentration	Final concentration	Quantity or Volume (20 mL)
CaCl2·2H2O	1 M	10 mM	200 μL
2-(N-morpholino) ethanesulfonic acid, pH 5.7	100 mM	5 mM	1 mL
Mannitol	1 M	0.5 M	10 mL
Adjust to final pH 5.7 with KOH 1 M

c. Wash solution

Component	Stock concentration	Final concentration	Quantity or Volume (50 mL)
CaCl2·2H2O	1 M	10 mM	500 μL
Mannitol	1 M	0.5 M	25 mL
Adjust to final pH 5.7 with KOH 1 M

d. W5 solution

Component	Stock concentration	Final concentration	Quantity or Volume (40 mL)
CaCl2·2H2O	1 M	125 mM	5 mL
2-(N-morpholino) ethanesulfonic acid, pH 5.7	100 mM	2 mM	800 μL
NaCl	1 M	154 mM	6.16 mL
KCl	500 mM	5 mM	400 μL

e. MMG solution

Component	Stock concentration	Final concentration	Quantity or Volume (10 mL)
Mannitol	1 M	0.4 M	4 mL
MgCl2·6H2O	500 mM	15 mM	300 μL
2-(N-morpholino) ethanesulfonic acid, pH 5.7	100 mM	4 mM	400 μL

f. PEG solution

Component	Stock concentration	Final concentration	Quantity or Volume (10 mL)
Mannitol	1 M	0.2 M	2 mL
CaCl2·2H2O	500 mM	100 mM	1 mL
PEG 4000	/	40%	4 g

Laboratory supplies

1. Steri vent container 107 × 94 × 96 mm (Duchefa Biochemie, catalog number: S1682)

2. Nylon filter 60 μM (AGRINOVA)

3. Petri dishes 92 × 16 (VWR, catalog number: 391-0493)

4. Petri dishes 60 × 15 (Greiner, catalog number: 628161)

5. Petri dishes 35 × 15 (Thermo Scientific, catalog number: 153066)

6. Sterile needles 0.7 × 50 mm (Henke Sass Wolf, catalog number: 471,0007050)

7. Sterile syringes 1 mL (Terumo, catalog number: MDSS01SE)

8. Sterile syringes 50 mL (NIPRO, catalog number: BSS131)

9. Sterile syringes 20 mL (BD Plastipak, catalog number: 300613)

10. Sterile centrifuge tubes, Falcon 15 mL (VWR, catalog number: VWRI525-0607)

11. Sterile centrifuge tubes, Falcon 50 mL (VWR, catalog number: VWRI525-0612)

12. Pipettes (Eppendorf)

13. Fast-Read102^® (Kova International, catalog number: BVS100H)

14. Filter 0.2 μm (Sarstedt, catalog number: 83.1826.001)

15. Pasteur 3 mL (Sarstedt, catalog number: D-51588)

16. Filter tips (2,5 μL, 20 μL, 200 μL, 1,000 μL, 5 mL)

17. Scalpel blades 21 and 11 (Duchefa)

18. Microscope slides

19. Coverslips

20. PCR tubes

21. 1.5 mL Eppendorf tubes

22. Sterile scalpels

23. Sterile forceps

24. Parafilm

Equipment

1. Heating magnetic stirrer (VWR^®, model: 442-0664)

2. pH meter (CRISON, model: BASIC 20⁺)

3. Weighing balance (OHAUS, model: AX422/E)

4. Analytical balance (OHAUS, model: PA114C)

5. Glass microsphere sterilizer (AgnTho’s AB, model: steri 250, Art-Nr 31’101)

6. ChemiDoc imaging system (Bio-Rad, model: 12003153)

7. Thermal cycler (Bio-Rad, model: S1,000)

8. Horizontal laminar flow cabinet (BIOAIR, model: aura HZ72)

9. PowerPac^TM basic power supply (Bio-Rad, model: 1645050)

10. Horizontal electrophoresis cells (Bio-Rad, model: Sub-Cell GT)

11. Horizontal electrophoresis cells (ELETTROFOR, models: OA-50; OA-78)

12. INCU-Line 150R (VWR^®, model: 390-1338)

13. Benchtop microcentrifuge (Eppendorf, catalog number: 5420)

14. Centrifuge (Eppendorf, model: 5804 R)

15. Stereomicroscopes (Leica, models: MZ16 F; EZ4)

16. Optical microscope (Leica, model: DM2500)

Procedure

All the following steps must be done under a laminar flow hood in order to maintain sterile conditions unless otherwise specified. Be sure to use sterile laboratory supplies and to have an available bead sterilizer in order to be able to periodically sterilize all the tools used to handle the plant material.

Embryogenic calli induction and long-term maintenance

A. Embryogenic calli induction from unopened leaves

1. Open the container in which the in vitro grapevine plantlets are present (Figure 1A).

2. Cut the unopened leaves near the apex of the shoots with a scalpel.

3. Collect all the leaves inside a Petri dish using forceps.

4. Prepare some Petri dishes with NB2 solid medium inside.

5. Still using forceps, place up to five unopened leaves inside each NB2 Petri dish (Figure 1B), with one side fully adjacent to the induction medium (abaxial side).

6. Incubate the NB2 petri dishes prepared with the plant material in full darkness at 27 °C for 6–7 weeks.

7. Check weekly for the evolution of the plant material in NB2 medium and the induction of embryogenic calli (Figure 1L).

Figure 1. Embryogenic calli induction and proliferation. A. In vitro grapevine plantlet. The arrow indicates the apex. B. In vitro leaf in NB2 medium (scale bar: 6 mm). C. Inflorescence from greenhouse-grown cutting. D. Grapevine flower (scale bar: 3 mm). Grey arrow indicates the calyptra, and blue arrow indicates the calyx. E. Stamen (scale bar: 0.5 mm). F. Pistil (scale bar: 0.5 mm). Pollen microsporogenesis stages: mother cells (G), tetrads (H), uninucleate pollen cells (I) (scale bars: 50 μm). L. In vitro leaf-induced embryogenic callus in NB2 medium (scale bar: 2 mm). M: Stamen/pistil-induced embryogenic callus in MSII/PIV media (scale bar: 2 mm). N: Embryogenic calli proliferated in C1^P medium (scale bar: 3 mm).

B. Embryogenic calli induction from stamens and pistils

1. Examination of the microsporogenesis development stage in anthers

Steps B1a–B1j can be performed in non-sterile conditions.

a. Collect a single flower from an inflorescence (Figure 1C).

b. Using a stereomicroscope, open the flower (Figure 1D) by cutting just below the calyptra with the sharp tip of a needle connected with a syringe in order to eliminate the calyx from the flower and maintain just the upper part with the calyptra, stamens, and pistil.

c. Still using a stereomicroscope, with two syringes, open the calyptra and reveal the stamens (Figure 1E) and the pistil (Figure 2F) inside.

d. Pick up all the stamens and place them on a microscope slide.

e. Crush the anthers in order to reveal the reproductive cells hidden inside (Figure 1G, H, I).

f. Soak the crushed material with 2–3 droplets of acetocarmine.

g. Cover the sample with a coverslip.

h. Observe the structures revealed in the crushed material under an optical microscope.

i. Repeat steps B1a–B1i by sampling different flowers from different parts of the inflorescence.

j. If all the observations show the microsporogenesis stage (Figure 1G, H, I) required, it is possible to proceed with the inflorescence sampling.

2. Inflorescence sampling and sterilization

a. Prepare the solution for the inflorescence sterilization (NaClO 3% and Tween-20 0.1%) in a Falcon tube.

b. Cut the entire inflorescence and immerse it in the sterilization solution.

c. Mix continuously by inversion for 10 min.

d. Discard the sterilization solution inside a collection container.

e. Fill the empty Falcon, which contains the inflorescence, with sterile double-distilled H₂O.

f. Mix continuously by inversion for 5 min.

g. Discard the water inside the collection container.

h. Repeat steps B2e, B2f and B2g two more times.

i. Using forceps, gently pick the inflorescence from the Falcon and place it in a new Petri dish.

j. Store the sterilized inflorescence at 4 °C up to 72 h.

3. Flower explants cultivation

a. Prepare a Petri dish with single drops of sterile double-distilled H₂O on different sides of the Petri dish.

b. Cut some flowers from the inflorescence with forceps and a scalpel and transfer them to the Petri dish prepared in the previous step.

c. Be sure to place the flowers inside sterile double-distilled H₂O droplets.

d. Using a stereomicroscope, with the sharp tip of a couple of sterile needles connected to two syringes, apply a cut in the flower just below the calyptra and discard the lower part of the organ (calyx).

e. Using needles, eliminate the calyptra and reveal the stamens and the pistil.

f. Gently pick the stamens and the pistil with the smooth part of the tip of a sterile needle, and one by one place them in a Petri dish with solid induction media (MSII or PIV) inside.

g. Place 52 explants (16 pistils and 36 stamens) in each induction media Petri dish.

h. Prepare up to 10 plates for each embryogenic calli induction medium.

i. Incubate for 2–4 months in darkness at 27 °C.

j. Using the stereomicroscope, check weekly the formation of embryogenic calli (Figure 1M).

C. Embryogenic calli proliferation

1. Selection of embryogenic calli and transfer in C1^P medium

a. Using a stereomicroscope, select white and granular shaped embryogenic calli (Figure 1M).

b. Mark the top of the Petri dish in correspondence with the explant selected for the propagation of the embryogenic calli.

c. Using a stereomicroscope, for each embryogenic callus selected (step C1b), collect all the embryogenic material emitted by the explant selected and transfer it to a new C1^P Petri dish.

d. Prepare one or more C1^P Petri dishes, each containing new embryogenic calli.

e. Using a scalpel, put embryogenic calli close to each other.

f. Repeat from step C1c to step C1e for each embryogenic callus (step C1b) selected.

g. Incubate the C1^P petri dishes in darkness at 27 °C for 4 weeks.

2. First subculture in C1^P medium and subsequent subcultures

a. Using a stereomicroscope, collect embryogenic material using a scalpel from 4-week-old C1^P Petri dishes (Figure 2N).

b. Transfer selected embryogenic material to a new C1^P Petri dish.

c. Prepare up to six new C1^P Petri dishes.

d. Adjust the position of the embryogenic callus as described in step C1e.

e. Repeat from step C2a to step C2d for all embryogenic callus selected (step C1b).

f. Incubate in darkness at 27 °C for 4 weeks.

g. Repeat the subculture process every 4 weeks and prepare in each cycle six C1^P Petri dishes with fresh embryogenic material for each embryogenic callus selected.

Protoplast isolation and cultivation

A. Preparation of embryogenic calli

1. Using a stereomicroscope, select compact and white cream-colored embryogenic callus from 4-week-old embryogenic culture masses grown in C1^P medium.

2. Transfer them to fresh C1^P medium.

3. Prepare up to seven C1^P plates.

4. Incubate them at 27 °C in darkness for 7–10 days.

B. Protoplasts isolation

1. Using forceps, transfer embryogenic calli (Figure 2A) to the 60 × 10 mm Petri dish. Additionally, transfer a small amount of embryogenic calli as control to the 35 × 10 mm Petri dish.

2. Weigh embryogenic calli collected in the 60 × 10 mm Petri dish and add 10 g/mL of filtered-sterilized digestion solution.

3. Add 1 mL of filtered-sterilized digestion solution without enzymes in the 35 × 10 mm Petri dish.

4. Incubate both Petri dishes in darkness for 5–6 h on a rotating shaker.

Figure 2. Protoplast isolation from embryogenic calli, analysis of cell wall digestion, and protoplast viability. A. Embryogenic callus (7–10 days) in C1 medium (scale bar: 2 mm). B. Protoplasts isolated from embryogenic calli following 5 h of incubation with digestion solution. C, D. Protoplasts stained with fluorescent brightener 28 under white (C) and UV (D) light. The absence of blue signal indicates the correct cell wall digestion. E, F. Embryogenic calli (control) stained with fluorescent brightener 28 under white (E) and UV (F) light. The blue signal indicates the presence of the cell wall. G, H. Protoplasts stained with FDA under white (G) and UV (H) light. The green fluorescent signal indicates that protoplasts are viable and therefore can be used for transfection and cultivation (Scale bars: 20 μm).

C. Monitoring of progression of cell wall digestion

1. After 90 min, take an aliquot from the Petri dish containing calli in digestion solution (step B4) and observe the progress of isolation under an optical microscope.

2. Repeat step C1 after 3 h of incubation.

3. After about 5–6 h of incubation (Figure 2B), evaluate the correct digestion of the cell wall by staining both protoplasts and control with 2 μM fluorescent brightener 28.

4. Mix by pipetting.

5. Prepare a microscope slide and observe both protoplasts (Figure 2C) and control (Figure 2E) under UV light (Figure 2D, F).

D. Protoplast filtration and washing

1. Filter protoplast in a new Petri dish using a 60 μm nylon sieve.

2. Gently transfer filtered protoplast to a 15 mL Falcon.

3. Centrifuge the mixture at 100× g for 6–8 min.

4. Remove the supernatant.

5. Completely resuspend the protoplast pellet in 2–3 mL of wash solution.

6. Add wash solution until a final volume of 5–10 mL.

7. Centrifuge at 100× g for 3 min at 20 °C.

8. Remove the supernatant.

9. Repeat steps D5 to D8.

10. Resuspend protoplast pellet in 3–5 mL of wash solution.

E. Evaluation of protoplasts viability by fluorescein diacetate (FDA) staining

1. Add 0.5 mg/mL FDA solution to a previously obtained aliquot of protoplasts mixture.

2. Mix by pipetting.

3. Prepare a microscope slide and observe protoplasts (Figure 2G) under UV light (Figure 2H).

F. Protoplasts count, cultivation, and analysis of regenerative structures

1. Prepare a 1:10 protoplast dilution in wash solution and place an aliquot in a counting chamber.

2. Determine the number of protoplasts obtained in 1 mL (protoplast/mL) using an optical microscope.

3. Proceed to protoplast cultivation, using a final concentration of 1 × 10⁵ ppt/mL.

4. Based on the yield obtained per milliliter, calculate the volume of suspension to obtain a quantity of 1 × 10⁵ protoplasts and transfer it into 15 mL Falcons.

5. Centrifuge at 100× g for 3 min.

6. Remove the supernatant.

7. Resuspend each pellet in 1 mL of solid culture medium for protoplast cultivation and prepare four drops for each 60 mm Petri dish.

8. Once the drops have solidified, add 4 mL of liquid culture medium for protoplast cultivation.

9. Incubate plates at 27 °C.

10. Monitor cell divisions and development of regenerative structures every week using an inverted microscope (Figure 3A–F).

Figure 3. Stages of regeneration from protoplasts. A. First cell division (scale bars: 30 μm). B. Further cell divisions (scale bars: 40 μm). C. Somatic embryo at early globular stage of development (scale bars: 50 μm). D. Somatic embryo at the early globular stage of embryo development (scale bars: 70 μm). E. Somatic embryo at the heart stage of embryo development (scale bars: 70 μm). F. Somatic embryo at the torpedo stage of embryo development (scale bars: 100 μm).

Protoplasts PEG-mediated transfection

A. RNA guide design

RNA guide design was performed using CRISPOR online software (http://crispor.tefor.net) and CRISPR-RGENE (http://www.rgenome.net).

B. RNA guide synthesis

RNA guide synthesis was conducted using the GeneArt Precision gRNA Synthesis kit following the instructions provided by the manufacturer. The main steps are as follows:

1. Design forward and reverse oligonucleotides for PCR assembly.

2. PCR-assemble the gRNA DNA template using the Phusion^TM High-Fidelity PCR master mix.

3. Generate the gRNA by in vitro transcription using the TranscriptAid^TM enzyme mix.

4. Remove the DNA template by DNase I degradation.

5. Purify the in vitro–transcribed gRNA using the GeneJET^TM purification columns.

6. Measure the purified gRNA concentration using Qubit RNA BR kit following the instructions provided by the manufacturer.

C. Cas9-sgRNA ribonucleoprotein complex assembly

To assemble the Cas9-sgRNA ribonucleoprotein complex, proceed as follows:

1. Add the Cas9 protein and sgRNA at a 1:1 weight ratio in a tube and mix gently.

2. Incubate for 10 min in darkness at room temperature.

D. PEG-mediated protoplasts transfection, cultivation, and analysis of regenerative structures

1. Add 2 × 10⁵ protoplasts in a sterile 15 mL falcon tube.

2. Centrifuge the protoplasts at 100× g for 3 min.

3. Remove the supernatant.

4. Gently resuspend the protoplasts in 200 μL of MMG solution.

5. Add the Cas9-sgRNA ribonucleoprotein complex preassembled as described above in section “Cas9-sgRNA ribonucleoprotein complex assembly”.

6. Add 200 μL of PEG solution.

7. Mix gently until the solution is completely homogenized.

8. Incubate the solution for 20 min in the dark at room temperature.

9. Wash the protoplasts by adding 2 mL of sterile W5 solution and mix gently.

10. Centrifuge the protoplasts at 100× g for 3 min.

11. Remove the supernatant.

12. Repeat steps D9 to D11.

13. Remove the supernatant and resuspend the protoplasts in 1 mL of solid culture medium for protoplast cultivation. Proceed with the protoplasts cultivation as indicated in section above “Protoplasts count, cultivation, and analysis of regenerative structures” (steps F7 to F9).

14. Monitor cell divisions and the development of regenerative structures every week using an inverted microscope (Figure 3A–3F).

Somatic embryogenesis and plant regeneration

A. Identification of somatic cotyledonary embryos

1. After 2–3 months, verify the correct development of mature somatic cotyledonary embryos (Figure 4A) regenerated from protoplasts using a stereomicroscope.

Note: This step can be performed in non-sterile conditions.

Figure 4. Plants regeneration from protoplasts. A. Mature cotyledonary somatic embryo (scale bar: 0.5 mm). B. Germinated somatic embryo. C. Young plantlet in shooting medium. D. Whole plant regenerated in vitro.

B. Germination of somatic cotyledonary embryos

1. Using a stereomicroscope, transfer mature somatic cotyledonary embryos from DC medium to full germination medium.

2. Incubate for 3–4 weeks in darkness at 27 °C.

C. Shoots and plantlets development

1. Transfer well-developed germinated somatic embryos (Figure 4B) with forceps to C2D, C2D-4B, MG1, and MG1-10B media.

2. Incubate for 5–6 weeks under light with a 16-h photoperiod.

D. Plantlets regeneration and in vitro whole plant development

1. Check the correct development of regenerated plantlets (Figure 4C).

2. Transfer plantlets with forceps to MSN and RIM plant development media.

Note: Regenerated plantlets from C2D and C2D-4B were transferred to MSN medium, while regenerated plantlets from MG1 and MG1-10B were transferred to RIM medium.

3. Maintain fully regenerated plantlets (Figure 4D) under light with a 16-h photoperiod.

Validation of protocol

As mentioned in Najafi et al. 2022, to confirm genome editing events, genomic DNA was extracted from leaves of each regenerated plantlet derived from RNP-transfected protoplasts. A PCR amplification was performed targeting the specific genomic region of interest. Finally, Sanger sequencing verified mutations of the target site, confirming the success and precision of the editing process.

General notes and troubleshooting

General notes

1. Collect young unopened leaves from the apex of in vitro grapevine plantlets (5–6 weeks old) using sterile forceps. "Unopened" refers to leaves where the two sides of the leaf flap are still closed. Place droplets of sterile double-distilled H₂O in a sterile Petri dish to maintain humidity.

2. Submerge inflorescences in water during processing and use two syringes to remove the calyptra, ensuring stamens remain attached to the pistil.

3. Embryogenic callus formation efficiency is dependent on the cultivar. Examine explants under a stereomicroscope for embryogenic material, which should appear white and granular. High-quality calli crumble apart when touched with a sterile scalpel.

4. After being placed in C1^P medium, not all selected calli will proliferate effectively; use only high-quality material for subsequent steps.

5. Use cut tips to minimize damage to protoplasts and evaluate viability with fluorescein diacetate (FDA) staining. Monitor cell wall digestion and handle protoplasts carefully to maintain integrity.

6. The tissue of origin for protoplast isolation, details in the purification steps, and the composition of the regeneration media may vary across plant species, whereas the type and concentration of enzymes in the digestion solution are quite standard regardless of the starting material.

Acknowledgments

E.B., E.D. and S.Ze. designed the research; E.B., S.Za., S.L., L.C. and C.C. performed the research and analyzed the data; A.A., M.F. and S.Ze. contributed to data analysis; E.B., E.D., S.Za., S.L., L.C. and C.C. wrote the paper. This work was supported by EdiVite s.r.l., Grant BAYER (University of Verona awarded to Sara Zenoni) and PRIN 2022 (University of Verona awarded to Sara Zenoni). This protocol is based on our recent publication [13].

Competing interests

The patent application N. 102021000023468 is based on this protocol.

References

1. Webb, L. B., Whetton, P. H. and Barlow, E. W. R. (2007). Modelled impact of future climate change on the phenology of winegrapes in Australia. Aust J Grape Wine Res. 13(3): 165–175. https://doi.org/10.1111/j.1755-0238.2007.tb00247.x
2. Massel, K., Lam, Y., Wong, A. C. S., Hickey, L. T., Borrell, A. K. and Godwin, I. D. (2021). Hotter, drier, CRISPR: the latest edit on climate change. Theor Appl Genet. 134(6): 1691–1709. https://doi.org/10.1007/s00122-020-03764-0
3. Zhang, Y., Massel, K., Godwin, I. D. and Gao, C. (2018). Applications and potential of genome editing in crop improvement. Genome Biol. 19(1): 910. https://doi.org/10.1186/s13059-018-1586-y
4. Jinek, M., Chylinski, K., Fonfara, I., Hauer, M., Doudna, J. A. and Charpentier, E. (2012). A Programmable Dual-RNA–Guided DNA Endonuclease in Adaptive Bacterial Immunity. Science (1979). 337(6096): 816–821. https://doi.org/10.1126/science.1225829
5. Li, M. Y., Jiao, Y. T., Wang, Y. T., Zhang, N., Wang, B. B., Liu, R. Q., Yin, X., Xu, Y. and Liu, G. T. (2020). CRISPR/Cas9-mediated VvPR4b editing decreases downy mildew resistance in grapevine (Vitis vinifera L.). Hortic Res. 7(1): 149. https://doi.org/10.1038/s41438-020-00371-4
6. Ren, C., Guo, Y., Kong, J., Lecourieux, F., Dai, Z., Li, S. and Liang, Z. (2020). Knockout of VvCCD8 gene in grapevine affects shoot branching. BMC Plant Biol. 20(1): 47. https://doi.org/10.1186/s12870-020-2263-3
7. Wan, D. Y., Guo, Y., Cheng, Y., Hu, Y., Xiao, S., Wang, Y. and Wen, Y. Q. (2020). CRISPR/Cas9-mediated mutagenesis of VvMLO3 results in enhanced resistance to powdery mildew in grapevine (Vitis vinifera). Hortic Res. 7(1): 116. https://doi.org/10.1038/s41438-020-0339-8
8. Clemens, M., Faralli, M., Lagreze, J., Bontempo, L., Piazza, S., Varotto, C., Malnoy, M., Oechel, W., Rizzoli, A., Dalla Costa, L., et al. (2022). VvEPFL9-1 Knock-Out via CRISPR/Cas9 Reduces Stomatal Density in Grapevine. Front Plant Sci. 13: e878001. https://doi.org/10.3389/fpls.2022.878001
9. Tu, M., Fang, J., Zhao, R., Liu, X., Yin, W., Wang, Y., Wang, X., Wang, X. and Fang, Y. (2022). CRISPR/Cas9-mediated mutagenesis of VvbZIP36 promotes anthocyanin accumulation in grapevine (Vitis vinifera). Hortic Res. 9: e1093/hr/uhac022. https://doi.org/10.1093/hr/uhac022
10. Malnoy, M., Viola, R., Jung, M. H., Koo, O. J., Kim, S., Kim, J. S., Velasco, R. and Nagamangala Kanchiswamy, C. (2016). DNA-Free Genetically Edited Grapevine and Apple Protoplast Using CRISPR/Cas9 Ribonucleoproteins. Front Plant Sci. 7: e01904. https://doi.org/10.3389/fpls.2016.01904
11. Osakabe, Y., Liang, Z., Ren, C., Nishitani, C., Osakabe, K., Wada, M., Komori, S., Malnoy, M., Velasco, R., Poli, M., et al. (2018). CRISPR–Cas9-mediated genome editing in apple and grapevine. Nat Protoc. 13(12): 2844–2863. https://doi.org/10.1038/s41596-018-0067-9
12. Bertini, E., Tornielli, G. B., Pezzotti, M. and Zenoni, S. (2019). Regeneration of plants from embryogenic callus-derived protoplasts of Garganega and Sangiovese grapevine (Vitis vinifera L.) cultivars. Plant Cell, Tissue Organ Cult. 138(2): 239–246. https://doi.org/10.1007/s11240-019-01619-1
13. Najafi, S., Bertini, E., D’Incà, E., Fasoli, M. and Zenoni, S. (2022). DNA-free genome editing in grapevine using CRISPR/Cas9 ribonucleoprotein complexes followed by protoplast regeneration. Hortic Res. 10(1): e1093/hr/uhac240. https://doi.org/10.1093/hr/uhac240
14. Reed, K. M. and Bargmann, B. O. R. (2021). Protoplast Regeneration and Its Use in New Plant Breeding Technologies. Front Genome Ed. 3: e734951. https://doi.org/10.3389/fgeed.2021.734951
15. Vezzulli, S., Gramaje, D., Tello, J., Gambino, G., Bettinelli, P., Pirrello, C., Schwandner, A., Barba, P., Angelini, E., Anfora, G., et al. (2022). Genomic Designing for Biotic Stress Resistant Grapevine. Genomic Designing for Biotic Stress Resistant Grapevine. In: Kole, C. (Ed.), Genomic Designing for Biotic Stress Resistant Fruit Crops (pp. 87–255). Cham: Springer. 87–255. https://doi.org/10.1007/978-3-030-91802-6_4
16. Gribaudo, I., Gambino, G., Boccacci, P., Perrone, I. and Cuozzo, D. (2017). A multi-year study on the regenerative potential of several Vitis genotypes. Acta Hortic. 1155: 45–50. https://doi.org/10.17660/actahortic.2017.1155.5
