Live-cell Imaging by Super-resolution Confocal Live Imaging Microscopy (SCLIM): Simultaneous Three-color and Four-dimensional Live Cell Imaging with High Space and Time Resolution

Materials and Reagents

1. 90 mm diameter Cell culture dishes, sterile (Iwaki, catalog number: SH90-15 )
2. 22 mm x 40 mm Micro cover glasses (Matusnami Glass, thickness No.1, 0.13-0.17mm)
3. 18 mm x 18 mm Micro cover glasses (Matusnami Glass, thickness No.1, 0.13-0.17mm)
4. 20 ml Syringes (Terumo, catalog number: SS-20ESZ )
5. Pipette tips, sterile (Sorenson, 1-200 µl Graduated tip, catalog number: 27730 )
6. Kimwipes (Nihon Seishi, catalog number: 62011 )
7. Tissue culture test plates, 24-well plate, sterile (TPP, catalog number: 92424 )
8. Toothpicks sterilized before use (any brand)
9. Budding yeast cells expressing two Golgi markers and secretory cargo tagged with different fluorescent proteins. (see Procedure B for details)
10. Silicon grease (Dow Corning Toray, catalog number: HVG-50 TUBE )
11. Concanavalin A (Sigma-Aldrich, catalog number: C2010 )
12. Yeast nitrogen base without amino acids (Difco Laboratories)
13. Casamino acids (Difco Laboratories)
14. Glucose (Nacalai Tesque)
15. Agar (Wako)
16. MCD agar plates (see Recipes)
17. MCD medium (see Recipes)


Equipment

1. Micropipette (Gilson, Pipetman, model: P200 )
2. Bio Shaker (Taitec, model: M-BR-022UP )
3. SCLIM (Figure 1) is equipped with:

   1. Inverted fluorescence microscope (Olympus, model: IX-73 )

   2. Objective lens (Olympus, UPlanSApo 100x NA 1.4 oil objective lens)

   3. Spinning-disk confocal scanner (Yokogawa Electric, CSU10 custom made model)
      Other type of CSU can be used (e.g., CSU10, CSUX1, CSUW1). Confocal scanner is equipped with custom made dichroic mirror having high spectroscopic properties for 3-color observation (Kurokawa et al., 2013).
   4. Excitation lasers: Solid-state 3 lasers with emission at 473 nm (Cobolt, CW 473nm, DPSS, 50 mW), 561 nm (Cobolt, CW 561 nm, DPSS, 50 mW), and 671 nm (CrystaLaser, CW 671 nm, DPSS, 100 mW)
      These 3 lasers can excite GFP, mRFP or mCherry, and iRFP simultaneously. Irradiation of the sample by these 3 lasers is controlled by 3 independent electromagnetic shutters (Sigma Koki). These shutters are operated by the demand of the custom-made software. Irradiation powers of 3 lasers can be adjusted with variable ND filters.
   5. Spectroscopic unit: A custom made system equipped with custom-made dichroic mirrors, reflection mirrors, band pass filters, and long pass filter to separate 3-color fluorescence (green, red, and infra-red) images to 3 different channels (Kurokawa et al., 2013)
      The angles of dichroic mirrors and reflection mirrors can be adjusted from outside of the spectroscopic unit.
   6. Magnification lens (NIKON, VM lens C-4x [4x] or C-4x plus C-2.5x [10x])
      A magnification lens is putted in the light path between the confocal scanner and spectroscopic unit for raising spatial resolution.
   7. EM-CCD cameras (Hamamatsu Photonics, C9100-13)
      They contain 512 x 512 frame transfer CCD sensor. Pixel size of sensor is 16 x 16 µm. 3 EM-CCD cameras are set up for taking green, red, and infra-red fluorescence images.
   8. Image intensifier (Hamamatsu Photonics)
      3 Image intensifiers are equipped with each 3 EMCCD cameras. Image intensifiers are cooled with a custom-made cooling system to achieve low signal-to-noise ratio amplification. The amplification gain of these 3 image intensifiers are controlled independently.
   9. Piezo actuator (Yokogawa Electric, custom made model)
      It is equipped at the neck of objective lens to oscillate Z-axis position of the lens at high frequency (maximum, 30 Hz). Normally, we use it at 4-15 Hz.
   10. Thermo-control stage (Tokai Hit)
       The temperature of the sample during observation can be controlled by thermo-control stage.
   11. Image acquisition system
       Custom made system controls simultaneous collection of 3 EM-CCD camera’s images at each Z-axis position and each time point (Yokogawa Electric).


       Figure 1. Set up of 3-color SCLIM. A. An inverted microscopy (a) is combined with, an ultra-fast piezo actuator (i), a custom-made spinning-disk confocal scanner (c), 3 excitation lasers (d), a magnifier lens (f), a custom-made spectroscopic unit (containing dichroic mirrors, refraction mirrors, and band-pass and long-pass filters) (e), 3 cooled image intensifiers (h), and 3 EM-CCD cameras (g). B. Another view of the custom-made spectroscopic unit (e), 3 cooled image intensifiers (h), and 3 EM-CCD cameras (g) is shown.

Software

1. Volocity software (PerkinElmer)
2. MetaMorph software (Molecular Devices)


Procedure

1. Preparation of a Concanavalin A-coated glass dish for imaging living yeast cells
   Concanavalin A is used to immobilize living yeast cells on the cover glass surface for microscopic observation.

   1. Make a square bank in 1-2 mm depth of 18 mm x 18 mm or less with silicon grease on a 22 mm x 40 mm cover glass (Figure 2A). Silicon grease is extruded from the syringe through a pipet tip with a cut end.


      Figure 2. Sample preparation. A. A square bank in 1-2 mm depth of 18 mm x 18 mm or less is made with silicon grease on a 22 mm x 40 mm cover glass. The cover glass surface within square bank is coated with Concanavalin A. B. An aliquot of yeast liquid culture is applied into the square bank of Concanavalin A-coated 22 mm x 40 mm cover glass. C. The yeast liquid culture is sandwiched by the Concanavalin A-coated cove glass and a 18 x 18 mm cover glass. The yeast cells are then subjected to microscopic observation.


   2. Apply about 25 µl of 0.2 mg/ml Concanavalin A on the cover glass within square bank.
   3. Wait for about 2 min to coat the cover glass with Concanavalin A.
   4. Remove the excess Concanavalin A solution from the glass surface.
   5. Dry Concanavalin A at room temperature for about 10 min. The Concanavalin A-coated glass dish needs to be freshly prepared for well immobilizing living yeast cells.


2. Preparation of yeast cells for the fluorescent microscopic pulse-chase assay of cargo transport
   Yeast temperature-sensitive mutants such as sec31-1 and uso1-1 show a defect in ER-to-Golgi cargo transport at the restrictive temperature (37 °C). By combining the gene expression of cargo by a heat-shock inducible promoter and the use of yeast temperature-sensitive mutants, the fluorescence microscopic pulse-chase assay has been established to visualize cargo transport from the ER to the Golgi and within the Golgi (Kurokawa et al., 2014 and 2019).

   1. Pick up temperature-sensitive mutant yeast cells expressing cargo and two Golgi cisternal markers (e.g., uso1-1 cells expressing heat-shock-inducible Axl2-GFP (transmembrane cargo) and constitutive Mnn9-mCherry (cis-Golgi marker) and Sys1-iRFP (trans-Golgi marker)) from a frozen stock using a sterile toothpick, and streak yeast cells on a MCD agar plate with appropriate amino acid supplements.
   2. Incubate yeast cells on the agar plate at 24 °C for 2-3 days.
   3. Inoculate yeast cells into 1 ml MCD medium with appropriate amino acid supplements in a 24-well plate by using a sterile toothpick.
   4. Grow yeast cells to the early-to-mid logarithmic phase at 24 °C with shaking at 500 rpm.
   5. Incubate yeast cells at 37 °C for 15-30 min to induce GFP-tagged cargo (Axl2-GFP) synthesis and to inhibit the ER-to-Golgi cargo transport.
   6. Apply about 100 µl of yeast liquid culture into a square bank of Concanavalin A-coated 22 mm x 40 mm cover glass (Figure 2B).
   7. Wait for 2 min until yeast cells are immobilized on a Concanavalin coated cover glass.
   8. Cover the square bank with 18 mm x 18 mm cover glass (Figure 2C).
      Note: Yeast cells can grow well because two cover glasses are spaced with silicone grease.
   9. Remove overflowing yeast liquid culture from sandwiched space of two cover glasses with Kimwipes.
   10. Place the cover glasses sandwiching yeast cells on a microscope stage with the Concanavalin coated larger glass down. The temperatures of the microscopic stage and objective lens can be set at 24 °C by an automatic thermo-control system.


3. Image acquisition with SCLIM
   1. Set up of SCLIM before observation
      Due to various factors, such as chromatic aberrations of lenses in the whole microscopic and spectroscopic system, the 3 different fluorescence signals coming from the same position (XYZ) may be projected to different positions (XYZ) of 3 cameras. To conduct simultaneous 3-color 3D and 4D observation, it is necessary to correct the XYZ misalignments of these fluorescence signals. SCLIM has devised a method to correct the misalignments of XYZ positions in 3 cameras by using fluorescence beads (see Procedure F). Setting up SCLIM needs an expert operator who has well known the optics of SCLIM system.
   2. Image acquisition
      Fluorescent molecules have a broad range of emission. Thus, for example, when GFP is expressed at a very high level, the fluorescence signal of GFP may be detected even by a camera with a longer-wavelength emission filer. Such a leakage of fluorescence signals is called as bleed-through or crosstalk. It is critical to avoid such bleed-through signals as much as possible. The powers of 3 excitation lasers and the amplification gains of 3 image intensifiers should be independently controlled to minimize bleed-through. Users need to be trained in how to operate SCLIM correctly for ‘Image acquisition’ step.

      1. Observe the yeast cells expressing cargo (heat-shock-inducible Axl2-GFP) and Golgi cisternal markers, cis-Golgi marker (Mnn9-mCherry) and trans-Golgi marker (Sys1-iRFP), by SCLIM. In these cells, we can observe that cis-Golgi cisterna labeled with Mnn9-mCherry matures to trans-Golgi cisterna labeled with Sys1-iRFP while maintaining Axl2-GFP cargo.

      2. 2D confocal fluorescence data are separated in the custom-made spectroscopic unit. GFP, mCherry, and iRFP fluorescence images finally pass through the spectral windows defined by 2 band pass filters (GFP; 490-545 nm, and mCherry; 580-660 nm) and 1 long pass filter (iRFP; 680 nm-) and are simultaneously collected by synchronized 3 EMCCD cameras.

      3. Collect Z slice of 3-color images at appropriate time intervals during observation time (e.g., at every about 5 seconds during total 2-3 min observation). An appropriate range of Z-axis (e.g., 3 μm cover about 80% of yeast cell volume) is scanned into optical slices 100 nm apart by the piezo actuator equipped to the objective lens.

      4. Raw data sets (Z slice 3-color images at each time points) are once stored in the TIFF format in the hard-disk memory of the image acquisition computer.


4. Reconstruction of 3D images from raw data sets and making of deconvolved 3D images using Volocity software
   1. Transfer raw data sets to the computer installed with Volocity software.
   2. Reconstruct 3D images from raw data sets using Volocity software.

      1. Select ‘Create new’ from Actions menu in Volocity to make Image sequence.

      2. Read out raw data sets in 3 channels into Image sequence to reconstruct 3D images at each time point (Figure 3A).

      3. Select ‘Remove Noise’ from the Tools menu and remove noise from all 3D images using a fine filter.

      4. Select ‘Change Colors’ from the Tools menu and change colors of 3 channels (e.g., GFP as green, mCherry as red, and iRFP as blue).

      5. Select ‘Correct Photobleaching’ from the Tools menu and correct for photobleaching of 3D images to maintain intensities that are reduced by photobleaching during the observation time.

      6. Select ‘Properties’ from the Edit menu and change information of XYZ pixel sizes in 3D images. Pixels of (X) and (Y) are 0.06 µm and pixel of (Z) is 0.1 µm when we use 100x objective lens and 4x amplification lens and scan Z-axis with optical slices 100 nm apart.

      7. Select ‘Fast restoration’ from the Tools menu and make deconvolved 3D images using PSF (point-spread function) parameters of 3 fluorescence proteins optimized for the spinning-disk confocal scanner. These parameters are made with ‘Calculated PSF’ in ‘Create new’ from Actions menu.

      8. Raw 3D images and deconvolved 3D images can be shown in different modes of viewing, XYZ mode (Figure 3B), 3D opacity mode (Figure 3C), and so on.


         Figure 3. Reconstruction of raw and deconvolved 3D images. A. Image sequence of raw data sets in 3 channels at each time point are shown. B. Reconstructed raw and deconvolved 3D images at one time point are shown in XYZ mode. C. Reconstructed raw and deconvolved 3D images at one time point are shown in 3D opacity mode. cis-Golgi (Mnn9-mcherry, red) and trans-Golgi (Sys1-iRFP, blue) existed dispersed in the cytoplasm. Some cargos (Axl2-GFP, green) were transported to their final destination, the plasma membrane. Other cargos localized within Golgi cisternae. Dotted circles in the images highlight the edges of yeast cells.



5. Presentation and analysis of 3D and 4D images
   1. Regions of interest in deconvolved 3D images can be manually selected. Present the images as XYZ mode and outline the region of interest using the selection tool (Figure 4A, left panel). Select ‘Crop to Selection’ from the Actions menu to create a new deconvolved 3D image (Figure 4A, right 2 panels). 3D images shown in 3D opacity mode can be presented at any desired angles (Figure 4A, right 2 panels).
   2. To analyze the change of fluorescence signal intensities over time, we make time-lapse movie of deconvolved 3D images using ‘Make Movie’ from the Movie menu (Video 1). Total fluorescence signal intensities of 3D images in 3 channels (green, red, and infrared) are collected to calculate relative fluorescence intensity values of e.g., Axl2-GFP (cargo, green), Mnn9-mCherry (cis-Golgi, red), and Sys1-iRFP (trans-Golgi, blue) using Metamorph (Figure 4B, Video 1). Note, by using 3D opacity mode, we can make 3D images viewed at various angles, which helps avoid collecting incorrect fluorescence signals of another Golgi cisterna (Figure 4B, arrowheads).
   3. To analyze correct localization of cargo and Golgi resident proteins, 3D images shown in 3D opacity mode at any angles can be used for line-scan analysis using MetaMorph (Figure 4C).


      Figure 4. Presentation and analysis of 3D and 4D images. A. Select the region of interest in XYZ mode image (left panel) to make a new cropped 3D image. Cropped 3D images are shown in 3D opacity mode at two different angles (right 2 panels). Cargos (Axl2-GFP, green) localized at the plasma membrane (arrowheads) and within the Golgi cisterna (dotted circles) labeled with both of cis- (Mnn9-mcherry, red) and trans-Golgi (Sys1-iRFP, blue) markers. B. 4D images (time-lapse 3D deconvolved images) are shown (left panels) (see also Video 1). The frame where Mnn9-mCherry signals disappeared was set as 0 s. Relative fluorescence intensities of Axl2-GFP (cargo, green), Mnn9-mCherry (cis, red), and Sys1-iRFP (trans, blue) at each time point are shown on the right. Maturation of Golgi cisterna with cargo was observed (dotted circles). The cisterna was labeled with cis-Golgi marker (Mnn9-mcherry, red) and trans-Golgi marker (Sys1-iRFP, blue) at the beginning (-25 s). It lost Mnn9-mcherry signals and gained Sys1-iRFP signals, and then it was labeled only with Sys1-iRFP at -5.6 s, indicating it matured to trans-Golgi. Finally, this cisterna matured to the TGN because Sys1-iRFP signals were disappeared at 11.2 s. Note, the angle showing 3D images is important to obtain the correct fluorescence intensities in one cisterna. Top view analysis alone of fluorescence intensities over time may have obtained incorrect values of red fluorescence, because arrowheads in left panels indicate another cis cisterna, which was present just below the analyzed cisterna. C. 3D deconvolved images were subjected to line scan analysis (upper panels). 3D deconvolved images (merged image, Axl2-GFP, Mnn9-mCherry, and Sys1-iRFP) at -16.8 s are shown (upper panels). Lower graph shows relative fluorescence intensities of Axl2-GFP (cargo, green), Mnn9-mCherry (cis, red), and Sys1-iRFP (trans, blue) along the white arrows in the maturing cisterna. Mnn9-mCherry and Sys1-iRFP showed segregated localization within the cisterna. Cargo located both regions.



      Video 1. Maturation of the Golgi cisterna with cargo viewed from two different angles


6. Checking and correcting the misalignments of XYZ positions in 3 cameras
   Before the observation of yeast cells expressing 3 fluorescence proteins, we always check and correct the misalignments of XYZ positions in 3 cameras by the following ways.

   Check and correct the misalignment in XY positions by using pinhole images of 3 cameras

   1. Stop the rotation of the spinning-disk of the confocal scanner.

   2. Apply a weak light from a halogen lamp light source to objective lens.

   3. Obtain the halogen light images passed through the pinhole with 3 cameras.
      Note: Because the gain of amplification in 3 Image Intensifiers are controlled independently, we can acquire images of almost the same intensities in 3 cameras.
   4. Adjust the angles of dichroic millers and reflection millers of the custom-made spectroscopic unit to correct the XY positions of 3 cameras’ images.


   Check and correct the misalignment in XYZ positions in 3 cameras by using bleed-through signals of fluorescence proteins using Volocity

   1. Prepare yeast cells expressing GFP (e.g., yeast cells expressing Sec13-GFP which show the dotted signals around the peripheral ER and nuclear membrane).

   2. Excite GFP with the 473 nm laser at high power and obtain emission signals and bleed-through signals of GFP simultaneously with 2 cameras for green and red fluorescence by adjusting the amplification gain of 2 Image Intensifiers. Check the misalignment in XYZ positions of emission signals and bleed-through signals from GFP dots in 2 cameras dedicated for green and red fluorescence.

   3. In the same way, obtain emission signals and bleed-through signals of red fluorescence (e.g., yeast cells expressing Sec13-mCherry) with 2 cameras dedicated for red and infrared fluorescence and then check the misalignment.

   4. Select ‘Registration Correction’ from Create New in Actions menu to create new registration correction parameters using the misalignment in XYZ positions in 3 channels.

   5. Select ‘Correct Registration’ from Tools menu and correct the misalignments in XYZ positions in 3 channels using the registration correction parameters.

Recipes

1. MCD agar plate
   0.67% yeast nitrogen base without amino acids
   0.5% casamino acids
   2% glucose
   2% agar

   1. Mix Yeast Nitrogen Base 3.4 g, Vitamin assay casamino acid 2.5 g, and Agar 10 g in 450 ml of distilled water

   2. Autoclave at 120 °C for 20 min

   3. Add 50 ml of 20% Glucose and 5 ml of appropriate amino acid supplements

   4. Pour the medium into a cell culture dish (approximately 20 ml/dish)

   5. Solidify the plates for 2-3 days before use and store at 4 °C

2. MCD media
   0.67% yeast nitrogen base without amino acids
   0.5% casamino acids
   2% glucose

   1. Mix Yeast Nitrogen Base 3.4 g and Vitamin assay casamino acid 2.5 g in 450 ml of distilled water

   2. Add 50 ml of 20% Glucose and 5 ml of appropriate amino acid supplements

   3. Store at room temperature
