Identification and Quantification of Secondary Metabolites by LC-MS from Plant-associated Pseudomonas aurantiaca and Pseudomonas chlororaphis

Materials and Reagents

1. Pipette tips (Axygen^TM 1,000 μl Universal Pipette Tips) (Corning, Axygen^®, catalog number: T-1000-B )

2. Sterile syringe filters of 0.2 µm (Corning, catalog number: 431225 )

3. Pasteur pipettes (e.g., Fisherbrand^TM disposable borosilicate glass Pasteur pipettes, Fisher Scientific, catalog number: 13-678-20A )

4. pH indicator strips (pH 0-14 Universal Indicator) (Merck, catalog number: 1095350001 )

5. Nine bacterial strains including eight isolates of Pseudomonas chlororaphis subsp. aurantiaca (GS-1, GS-3, GS-4, GS-6, GS-7, ARS-38, PBSt-2, FS-2) and one Pseudomonas chlororaphis subsp. chlororaphis (RP-4) isolate

6. Hydrochloric acid (HCl), 36.5-38% (Sigma-Aldrich, catalog number: 320331 )

7. Ethyl acetate, EMSURE^® ACS, ISO, Reag. Ph Eur. (Merck, catalog number: 1096232500 )

8. Sodium sulfate, anhydrous, ≥ 99% (Sigma-Aldrich, catalog number: 1614807 )

9. Methanol gradient grade for liquid chromatography, LiChrosolv^® Reag. Ph Eur (Merck, catalog number: 1060072500 )

10. Chloroform, EMSURE^® ACS, ISO, Reag. Ph Eur. (Merck, catalog number: 1024452500 )

11. Water, LC-MS grade, LiChrosolv^® (Merck, catalog number: 1153332500 )

12. Dimethyl sulfoxide (DMSO), ≥ 99% (Sigma-Aldrich, catalog number: 472301 )

13. Formic acid, 98-100%, EMSURE^® ACS, ISO, Reag. Ph Eur. (Merck, catalog number: 1002640510 )

14. Acetonitrile gradient grade for liquid chromatography, LiChrosolv^® Reag. Ph Eur (Merck, catalog number: 1000302500 )

15. Protease-peptone, microbiology grade (Sigma-Aldrich, catalog number: 82450 )

16. Glycerol, molecular biology grade, ≥ 99.5% (Sigma-Aldrich, catalog number: G9012 )

17. Potassium phosphate dibasic (K₂HPO₄), ACS reagent, ≥ 98% (Sigma-Aldrich, catalog number: P3786 )

18. Magnesium sulfate heptahydrate (MgSO₄·7H₂O), ACS reagent, ≥ 98% (Sigma-Aldrich, catalog number: 230391 )

19. Agar (for solid medium only), powder for Microbiology (Sigma-Aldrich, catalog number: 05040 )


Equipment

1. Microbiological static incubator (e.g., Memmert, model: IF55 standard incubator )

2. Microbiological incubator shaker (e.g., IKA, model: KS 4000 i control )

3. Pipettes (e.g., Sartorius, catalog numbers: 728020 , 728050 , 728060 and 728070 )

4. Large-volume centrifuge (e.g., HERMLE Labortechnik, model: Centrifuge ZK 496 )

5. Erlenmeyer flasks (e.g., PYREX^TM, 1,000 ml, 500 ml, Corning, PYREX^®, catalog number: 4980-1L )

6. Separatory funnels with stopcock and ring stand (e.g., 1,000 ml, 500 ml, VWR, catalog number: 89426-640 )

7. Autoclave

8. Glass beakers (e.g., PYREX^TM, 1,000 ml, 500 ml, 100 ml, 50 ml, DWK Life Sciences, KIMBLE, catalog number: 14000-2000 )

9. Glass stirrer

10. Rotary evaporator (e.g., Buchi Rotavapor^® R-100 (BÜCHI Labortechnik, model: Rotavapor^® R-100 ) with Re-circulating Chiller F-100/F-105 (BÜCHI Labortechnik, model: Recirculating Chiller F-100/F-105 ), Vacuum Pump V-100 (BÜCHI Labortechnik, model: Vacuum Pump V-100 ), water bath and Interface I-100 (BÜCHI Labortechnik, model: Interface I-100 ))

11. Fume hood (e.g., Labconco, model: 4’ Protector XStream Laboratory Hood, catalog number: 110410000 )

12. LC-MS (e.g., Thermo Finnegan LC-MS, ESI Ion Trap Mass Spectrometer, Thermo Electron, model: LCQ Advantage Max )

13. TLC plates (Silica Gel 60G F₂₅₄ 20 x 20 cm, e.g., Merck, catalog number: 100390 )

14. C18 column for MS (e.g., Thermo Hypersil Gold C18 column, Length 250 mm, 4.6 mm ID, 5 µm particle size, Thermo Fisher Scientific, catalog number: 25005-254630 , Lot No. 7648, S/N 0871381M)

15. HPLC system (e.g., WATERS, model: e2995 Separations Module , 2998 Photodiode Array (PDA) Detector)

16. HPLC column (e.g., Nucleosil C18 column, 4.6 x 250 mm, 5 µM; Macherey-Nagel, Germany)


Software

1. Xcalibur 2.0 software (Xcalibur^TM Software, control and process data from LC-MS instruments. It is Windows^TM based software that provides method setup, data acquisition, data processing and reporting. Data files are retrieved in Qual Browser and are processed for interpretation and analysis)

Procedure

1. Culture conditions
   1. Total nine bacterial strains including eight isolates of Pseudomonas chlororaphis subsp. aurantiaca (GS-1, GS-3, GS-4, GS6, GS-7, ARS-38, PBSt-2, FS-2) and one isolate Pseudomonas chlororaphis subsp. chlororaphis (RP-4) were included in this research. These bacterial strains are 16S rRNA identified and screened for their PGPR activities (Shahid et al., 2017). All bacterial strains were streaked on King’s B agar plates (see Recipes) and plates were incubated at 28 ± 2 °C for 48 h.

   2. A single colony of each bacterial strain; GS-1, GS-3, GS-4, GS6, GS-7, ARS-38, PBSt-2, FS-2 and, RP-4 was separately used to inoculate 10 ml of King’s B broth. Cultures were incubated in a shaking incubator for 24 h at 150 rpm and 28 ± 2 °C. Next day, each bacterial culture was individually inoculated (2%) in 500 ml King’s B broth and flasks were incubated at 28 ± 2 °C, 150 rpm for 96 h.


2. Extraction procedure

   1. After 96 h of incubation, harvest cultures and centrifuge at 3,376 x g for 40 min at 4 °C. Collect supernatants in separate flasks.

   2. All supernatants are acidified to pH 2 with 1 N HCl and pH is monitored with pH-indicator strips.

   3. Acidified supernatants are extracted twice with equal volume of ethyl acetate. For this, in each flask with 500 ml of acidified supernatant, add 500 ml of ethyl acetate. Put flasks in a shaking incubator for 10-15 min and then transfer materials into separatory funnels. The materials will separate into two phases, organic phase and water phase. The upper phase is organic phase while the lower phase has culture supernatant. Collect them into separate beakers. Re-extract the collected culture supernatant with ethyl acetate and combine the re-extracted organic layer into the previous collected organic phase.

   4. Add 20-30 g of anhydrous sodium sulphate to the beaker with organic phase and stir with a glass stirrer. This step is essential to remove any moisture from the organic layers. Then, transfer this content to another clean and dry beaker (avoiding any salt particles) and finally in the rotary evaporator flask.

   5. Turn on all basic units of rotary evaporator including central interface, glass assemblies, water bath, chiller, and vacuum. Set water bath temperature to 40-45 °C, and adjust rotary rotations accordingly to prevent any bumping of liquid in glass assemblies. When the liquid phase is completely dried, separate the round bottom flask with dried residue from rotary evaporator glass assembly.

   6. Re-dissolve residues of extracts in methanol and chloroform (2 ml methanol:2 ml chloroform), completely dry in a fume hood and store at 4 °C.


3. Identification of bacterial compounds using LC-MS

   1. For characterization of bacterial secondary metabolites, dissolve the extracts in 1.5 ml of methanol and 500 µl of chloroform.
      Note: Please be sure that extracts are completely dissolved and no un-dissolved residue left in the vials. If any portion of extracts remains undissolved, collect the methanol and chloroform soluble part in separate vials and dissolve the remaining undissolved part in DMSO (Dimethyl sulfoxide).

   2. Take 500 µl of these extracts and individually filter with sterile syringe filters of 0.2 µm (Fisher Scientific).

   3. Subject the extracts of all strains to Liquid Chromatography-Electrospray Ionization-Mass Spectrometry (LC/ESI/MS), for identification of secondary metabolites.

   4. Set up the instrument and perform LC-ESI MS/MS runs using a Thermo Finnegan HPLC system, coupled to an LCQ Advantage Max ESI-Ion Trap Mass Spectrometer (Thermo Electron, USA).

   5. Chromatographic separations are achieved using Thermo Hypersil Gold C18 column (4.6 x 250 mm, 5 µm particle size). Set the temperature of the column compartment at 25 °C, and load 20 µl of injection volume on the column.

   6. A gradient used to separate the metabolites consists of two solvent systems. Solvent A is 0.1% formic acid in water and solvent B is 0.1% formic acid in acetonitrile. Total LC-MS/MS runtime is 55 min, and set the flow rate at 0.7 ml/min.


4. Gradient conditions of LC-MS/MS

   1. Set gradient conditions as follows (Table 1):

      Table 1. Gradient run used for LC-MS and HPLC analyses



   2. ESI positive mode is used for the runs with data dependent protocol with a mass range of 150-1,500 a.m.u. and two scan events are employed for this data. The first scan event is a full scan of 150-1,500 and the second scan is dependent on the most abundant ions in the first scan triggering their MS² acquisition.

   3. Data are acquired at the normalized collision energy of 30%. The heated capillary is maintained at 350 °C, and sheath and auxiliary/sweep gases are at 60 and 25 arbitrary units, respectively.

   4. Set the source voltage to 4.5 kV with 10 V capillary voltage. The ESI-mass spectra obtained are used to characterize the surfactant ionization behavior; [M + H]⁺ and [M + Na]⁺ ions are monitored for phenazines, i.e., 2-hydroxy-phenazine(2-Oh-Phz) and phenazine-1-carboxylic acid (PCA); Lahorenoic acid A, and cyclic lipopeptide (WLIP). In addition, the ESI-MS/MS fragmentation behavior of identified peaks is investigated to confirm the structure of these secondary metabolites. Figures (Figures 1-3 and Supplemental Figures S1-S10) describe the structures, extracted ion current (XIC) chromatograms, mass spectrums and MS/MS fragmentation behavior of detected metabolites. Chemical formulas, exact masses and observed m/z values for detected metabolites have been given in Table 2.


      Figure 1. Structures of the compounds isolated from Pseudomonas aurantiaca and Pseudomonas chlororaphis. A. 2-hydroxyphenazine, B. phenazine-1-carboxylic acid, C. white-line-inducing principle, D. lahorenoic acid A (Mehanz et al., 2013).

      Table 2. Chemical formulas, exact masses and observed m/z values for detected metabolites



      Figure 2. Extracted ion current (XIC) chromatograms for 2-hydroxyphenazine (2-OH-Phz), m/z 197, [M + H]⁺ of four strains; ARS-38, RP-4, FS-2 and PB-St2


      Figure 3. Mass spectrum of 2-Hydroxyphenazine, m/z [M + H] ⁺ 197.07


5. Thin layer chromatography (TLC) of identified secondary metabolites
   Identified four secondary metabolites can also be analyzed by thin layer chromatography (TLC), using PB-St2 as a reference strain. PB-St2 is used as reference strain as all of its secondary metabolites have previously been published (Mehnaz et al., 2009 and 2013).
   1. For thin layer chromatography, load methanol fractions of all bacterial extracts (10 µl) on TLC plates (Silica Gel 60G F₂₅₄ 20 x 20 cm). Mobile phase contains chloroform: acetone: acetic acid (78.4:20:1.6, v/v/v) and samples are spot inoculated on TLC plate for separation (Figure 4).

   2. Air dry TLC plates (approximately for 5-10 min) and analyze for showing the separation of phenazines, i.e., phenazine-1-carboxylic acid (PCA) and 2-hydroxy phenazine (2-OH-Phz).


      Figure 4. Thin layer chromatogram of phenazine-1-carboxylic acid (PCA) and 2-hydroxy phenazine (2-OH-PHZ), present in cell-free supernatants of bacterial extracts of RP-4, ARS-38, GS-4 and FS-2. PB-St2 fractions were used as reference standard for this TLC analysis.


6. Quantification of secondary metabolites
   1. Manually collect the pure fractions of these compounds using HPLC from PB-St2 Pseudomonas aurantiaca isolate (or any bacterium that needs to be analyzed for its secondary metabolites) and analyze on LC-MS for their purity (Figure 5). The method for LC-MS is the same as used in HPLC analysis. The total run time is 55 min, with 20 µl injection volume and with same acetonitrile and water gradient run, as described in Table 1.

   2. Analyze samples on Waters HPLC System (e2995, separations module) with 299 h photodiode-array (PDA) detector using a Nucleosil C18 column (4.6 x 250 mm, 5 µM; Macherey-Nagel, Germany). Collected fractions of these compounds are used as reference standard to quantify the production of these compounds from all bacteria used in this study.


      Figure 5. HPLC analysis of enriched P. aurantiaca PB-St2 fractions of detected metabolites


Data analysis

All LC-MS/MS data were acquired and data files were processed using Xcalibur 2.0 software. Data files were initially open using Xcalibur FTMS raw data files. These files displayed total ion chromatogram (TIC) on the top and m/z spectra of total scan at the bottom. Using software’s basic features, data were acquired for reported four compounds and their ESI-MS/MS fragmentation patterns were also observed to confirm the structure of these secondary metabolites. ESI-MS/MS fragmentation was also confirmed with Wishart Research Group’s (CFM-ID), Competitive Fragmentation Modeling for Metabolite Identification (cfmid.wishartlab.com).

Notes

1. Avoid any plastic equipment during the preparation of samples for HPLC or LC-MS and also at the time of extraction. This may add some plasticizers in your prepared samples that often result in false peaks in LC-MS and HPLC run.

2. Amount of the culture medium can also be reduced accordingly. This method used the fractions extracted from 500 ml of King’s B broth. It can be reduced to 100 ml or 50 ml according to the requirement. Amount of organic solvents used will also get reduced with it.

3. For extraction with ethyl acetate, the supernatant is acidified to pH 2, while using dichloromethane (DCM) for extraction of secondary metabolites, the supernatant is not acidified/pH not changed.


Recipes

1. King’s B agar and broth
   Protease peptone 20 g/L
   Glycerol 20 g/L
   Anhydrous K₂HPO₄ 1.5 g/L
   MgSO₄·7H₂O, 6.09 ml of 1 M solution
   Agar (for solid medium only), 15 g/L
   Deionized H₂O, 1,000 ml
   Completely dissolve protease peptone, glycerol and anhydrous K₂HPO₄ in 500 ml of deionized H₂O and adjust the pH to 7.2. Make up the final volume to 994 ml and autoclave for 20 min. Separately, prepare 1 M solution of MgSO₄·7H₂O and autoclave it. Add 6.00 ml of this solution to the autoclaved medium for making up the final volume to 1,000 ml
