Analysis of Phagosomal Antigen Degradation by Flow Organellocytometry

Materials and Reagents

Note: The entire method is performed with sterile pyrogen-free dishes and plates, pipettes, tips, microfuge and conical tubes. All media and buffers need to be filtered through 0.22 μm filters.

1. Petri dish, 145 x 20 mm (Greiner Bio One, catalog number: 639161 )

2. 2 ml tubes

3. 15 ml centrifuge tube

4. U-bottom 96-well storage plate (Corning, Falcon^®, catalog number: 353077 )

5. V-bottom 96-well storage plate (Corning, Falcon^®, catalog number: 353263 )

6. 2 ml sterile syringe (Henke Sass Wolf, catalog number: 4020.000V0 )

7. 22 G sterile needle, 0.7 x 40 mm (Terumo Europe, catalog number: NN-2238R )

8. Mice: C57BL/6J (Janvier Labs)

9. Particles: amine-modified polystyrene microspheres, 3 μm diameter (Polysciences, catalog number: 17145-5 )

10. Dulbecco’s phosphate-buffered saline, no calcium, no magnesium (DPBS) (Thermo Fisher Scientific, Gibico^TM, catalog number: 14190094 )

11. Glutaraldehyde, 25% (vol/vol), EM grade (Electron Microscopy Sciences, catalog number: 16220 )

12. Low endotoxin ovalbumin (OVA) (Worthington Biochemical, catalog number: LS003062 )

13. Glycine, 0.5 M in PBS (Biosolve, catalog number: 07132391 )

14. CO₂-independent medium (Thermo Fisher Scientific, Gibco^TM, catalog number: 18045088 )

15. Glutamax supplement (100x) (Thermo Fisher Scientific, Gibco^TM, catalog number: 35050061 )

16. Iscove’s modified Dulbecco’s medium (IMDM) (Thermo Fisher Scientific, Gibco^TM, catalog number: 31980030 )

17. Low endotoxin fetal bovine serum (FBS, heat-inactivated for 20 min at 56 °C) (Biowest, catalog number: S1860 )

18. β-mercaptoethanol (50 mM) (Thermo Fisher Scientific, Gibco^TM, catalog number: 31350010 )

19. Penicillin-streptomycin (10,000 U/ml) (Thermo Fisher Scientific, Gibco^TM, catalog number: 15140122 )

20. Bovine serum albumin (BSA) (Sigma-Aldrich, catalog number: A4503 )

21. Anti-chicken egg albumin (OVA antibody) (Sigma-Aldrich, catalog number: C6534 )

22. Purified rat anti-mouse CD16/CD32 monoclonal antibody (Fc block) (BD, Pharmingen^TM, catalog number: 553142 )

23. Anti-mouse LAMP-1 antibody, biotin conjugate (Affymetrix, eBioscience, catalog number: 13-1071-82 )

24. Goat anti-rabbit IgG (H+L) antibody, DyLight 633 conjugate (Thermo Fisher Scientific, Invitrogen^TM, catalog number: 35562 )

25. Goat anti-rabbit IgG (H+L) antibody, Alexa Fluor 568 conjugate (Thermo Fisher Scientific, Invitrogen^TM, catalog number: A11036 )

26. Streptavidin, Alexa Fluor^® 488 conjugate (Thermo Fisher Scientific, Molecular Probes^TM, catalog number: S11223 )

27. Imidazole (Sigma-Aldrich, catalog number: I-0250 )

28. Sucrose (EMD Millipore, catalog number: 107651 )

29. Phenylmethanesulfonyl fluoride (PMSF) (Sigma-Aldrich, catalog number: P-7626 )

30. EDTA-free protease inhibitor cocktail (Sigma-Aldrich, catalog number: 11873580001 )

31. Dithiothreitol (DTT) (EMD Millipore, catalog number: 233155 )

32. Trypan blue solution, 0.4% (wt/vol) (MP Biomedicals, catalog number: 0916910 )

33. Internalization medium (see Recipes)

34. BMDC culture medium (see Recipes)

35. Homogenization buffer (see Recipes)


Equipment

1. Vortex

2. Refrigerated centrifuge for tubes of 2 ml, 15 ml and 50 ml size as well as 96-well plates

3. Tissue culture incubator adjusted to 37 °C and 5% CO₂

4. Stuart test tube rotator wheel tolerating 4 °C (Bibby Scientific, model: SB3 )

5. Temperature-controlled water bath

6. Pipets

7. Tissue culture light microscope equipped with bright field and 20x objective

8. Multi-channel pipet

9. LSR II flow cytometer (BD) or any other multicolour flow cytometer


Software

1. FlowJo software (FlowJo, LLC.)

2. Prism 6 software (GraphPad Software, Inc.)


Procedure

1. Preparation of antigen-coupled particles
   Note: Estimate the number of cells, which will be used for this assay, in advance to prepare a sufficient amount of particles coupled to OVA the day before the experiment. The stock suspension of 3 μm microspheres contains 1.68 x 10⁹ particles/ml.
   Example: Estimate the amount of cells you will harvest based on the amount of dishes in culture (for example 20 x 10⁶ cells in total from four 145 mm dishes of BMDC). Multiply this number by 10 (the amount of beads provided per cell) and divide by the concentration of beads (1.68 x 10⁹ particles/ml).



   1. Vortex suspension of amine-modified polystyrene microspheres thoroughly and distribute into 2 ml tubes (max. 200 μl/tube).

   2. Add 1.6 ml PBS to each tube, vortex and spin for 3 min at 16,000 x g at 4 °C.

   3. Discard supernatant, resuspend the pellet in 1.8 ml PBS and vortex. Spin again.

   4. Discard supernatant and resuspend the pellet in 8% glutaraldehyde/PBS (vol/vol). Use five times the volume of beads, which was used initially (e.g., 200 μl in 1 ml).

   5. Vortex and combine all suspensions in a 15 ml centrifuge tube. Protect the tube from light and incubate for 4 h on a test-tube rotator at 20 rpm at room temperature.

   6. Transfer suspension back into 2 ml tubes and spin them for 3 min at 16,000 x g at 4 °C.

   7. Discard supernatant, resuspend and vortex pellet in 1.8 ml PBS. Spin again.

   8. Discard supernatant and resuspend the pellet in 0.5 mg/ml OVA/PBS (Use five times the volume of beads that was used initially [e.g., 200 μl in 1 ml]).

   9. Vortex and combine all suspensions in a 15 ml centrifuge tube. Incubate overnight on a test-tube rotator at 20 rpm at 4 °C.

   10. Transfer suspension back into 2 ml tubes and spin them for 3 min at 16,000 x g at 4 °C.

   11. Discard supernatant, resuspend and vortex pellet in 1.8 ml 0.5 M glycine/PBS.

   12. Incubate for 30 min on a test-tube rotator at 20 rpm at 4 °C.

   13. Spin tubes for 3 min at 16,000 x g at 4 °C.
   14. Discard supernatant, resuspend and vortex pellet in 1.8 ml PBS.

   15. Repeat the spin followed by two more washes with 1.8 ml PBS (a total of three washes).

   16. Resuspend each pellet in the initial volume (200 μl), pool and vortex the dispersion. Store the suspension of OVA-coupled microspheres at 4 °C.
       Note: Coupled microspheres should be prepared freshly the day before the flow organellocytometry experiment and can be used within a week when stored at 4 °C. Never freeze particles and always vortex dispersion carefully to avoid aggregation of coupled microspheres.


2. Phagocytosis of antigen-coupled particles
   Note: Estimate around 5 x 10⁶ cells for each experimental condition.

   1. Pick up cell clusters and single cells by resuspending them with a pipet. Spin cells for 4 min at 400 x g at 4 °C.

   2. Resuspend cells in ice-cold PBS and spin them again for 4 min at 400 x g at 4 °C.

   3. Resuspend cells in ice-cold internalization medium, transfer them to a conical 15 ml centrifuge tube and count the cells.

   4. Adjust the cell suspension in ice-cold internalization medium to a cell density of 20 x 10⁶/ml and keep them on ice.

   5. Vortex suspension of OVA-coupled microspheres and add them to the cells at a particle-to-cell ratio of 10:1. Mix carefully.

   6. Incubate samples for 30 min in a water bath adjusted to 16 °C. If necessary, add ice to the water bath during the incubation period.

   7. Place samples on ice and add 10 ml ice-cold PBS to the tubes. Pipet up and down, close the tubes and shake them thoroughly for 10 sec. Spin tubes for 4 min at 100 x g at 4 °C to remove floating particles.

   8. Discard supernatant and repeat the last step twice to have a total of three washes.

   9. Resuspend each cell pellet in pre-warmed BMDC culture medium and divide cell suspension in 15 ml centrifuge tubes to allow phagosomal antigen degradation to occur for different time points. Use 1-2 ml medium for each experimental condition.

   10. Add 10 ml ice-cold PBS to one tube, which represents the time point of 0 min. Keep this tube on ice.

   11. Keep the other tubes open and incubate them at 37 °C and 5% CO₂ for different chase periods (for example: 60 and 120 min).

   12. Stop each chase period by adding 10 ml of ice-cold PBS and keep these tubes on ice.


3. Manual lysis and labeling of samples
   Note: After phagocytic uptake of particles, cells undergo a labeling step that distinguishes surface-bound particles from internalized ones. Subsequently, cells are lysed manually to release cytosol and cell organelles followed by a labeling step to detect levels of phagosomal OVA as well as the acquisition of lysosomal markers (for example, LAMP-1) to phagosomes during phagosome maturation.

   1. Spin all tubes for 4 min at 400 x g at 4 °C.

   2. Discard supernatant and resuspend each pellet in PBS + 1% (wt/vol) BSA. Transfer samples to a U-bottom 96-well plate.

   3. Spin the plate for 4 min at 400 x g at 4 °C and flick the supernatant.

   4. Resuspend each sample in 0.2 ml PBS + 1% (wt/vol) BSA + 1:100 diluted CD16/CD32 antibody (Fc block). Incubate on ice for 10 min.

   5. Spin the plate for 4 min at 400 x g at 4 °C and flick the supernatant.

   6. Resuspend each sample in 0.2 ml PBS + 1% (wt/vol) BSA + 1:500 diluted OVA antibody. Incubate on ice for 15 min.

   7. Spin the plate for 4 min at 400 x g at 4 °C and flick the supernatant.

   8. Resuspend each sample in 0.2 ml PBS and spin the plate for 4 min at 400 x g at 4 °C. Flick the supernatant and repeat the wash.

   9. Resuspend each sample in 0.2 ml PBS + 1% (wt/vol) BSA + 1:1,000 diluted anti-rabbit Alexa Fluor 568. Incubate on ice for 15 min.

   10. Spin the plate for 4 min at 400 x g at 4 °C and flick the supernatant.

   11. Resuspend each sample in 0.2 ml PBS and spin the plate for 4 min at 400 x g at 4 °C. Flick the supernatant and repeat the wash.

   12. Transfer samples into conical 1.5 ml centrifuge tubes and spin them for 4 min at 400 x g at 4 °C.

   13. Aspirate the supernatant carefully and resuspend each cell pellet in 0.5 ml homogenization buffer.

   14. For mechanical lysis of the cells, pass the suspension 15 times thoroughly through a 22 G needle fitted to a 2 ml syringe. Use the whole volume of the syringe for mechanical breaking of cells. Control homogenization success by trypan blue staining (Figure 1): Add 1 μl sample to 9 μl 0.4% (wt/vol) trypan blue solution, mix and add to a cell culture counting chamber. Count the amount of unstained, intact cells as well as stained, lysed cells using a light microscope. Calculate the percentage of lysed cells and do not exceed 80% of lysed cells. Additionally, avoid breaking of cell nuclei.


       Figure 1. Mechanical lysis of BMDC after uptake of OVA-coupled beads to release phagosomes for subsequent flow organellocytometry. BMDC were allowed to internalize OVA-coupled beads for 30 min followed by a chase period to allow phagosome maturation to occur. To break cells mechanically in order to release intact phagosomes without breaking cell nuclei, we pass the cell suspension 15 times through a 22 G needle. The image shows the cell suspension labeled with trypan blue before (upper panel) and after cell lysis (lower panel). Accumulation of trypan blue in cells with broken cell membrane but intact nuclei (arrows) allows one to monitor success of mechanical cell lysis. The release of phagosomes in the obtained post-nuclear supernatant (PNS) is visualized by bright field microscopy. Scar bar = 20 μm.


   15. Spin the tubes for 4 min at 150 x g at 4 °C to separate the post-nuclear supernatant (PNS) from cell nuclei and remaining intact cells.

   16. Transfer the PNS of the different samples into a V-bottom 96-well plate and keep on ice.

   17. Spin the plate for 3 min at 1,500 x g at 4 °C and remove supernatant with a multi-channel pipet.

   18. Add 50 μl PBS + 1% (wt/vol) BSA + 1:500 diluted OVA antibody + 1:100 diluted LAMP-1 antibody.

   19. Mix samples with a multi-channel pipet, seal the plate and incubate overnight on ice.

   20. Add 0.15 ml PBS + 0.1% (wt/vol) BSA to each well, spin the plate for 3 min at 1,500 x g at 4 °C and remove supernatant with a multi-channel pipet.

   21. Add 0.2 ml PBS + 0.1% (wt/vol) BSA and mix samples with a multi-channel pipet.

   22. Spin the plate again and repeat the wash with PBS + 0.1% (wt/vol) BSA once more.

   23. After the supernatant is removed with a multi-channel pipet, add 50 μl PBS + 1% (wt/vol) BSA + 1:1,000 diluted anti-rabbit DyLight 633 + 1:1,000 diluted streptavidin Alexa Fluor 488. Incubate on ice for 45 min.

   24. Add 0.15 ml PBS + 0.1% (wt/vol) BSA to each well, spin the plate for 3 min at 1,500 x g at 4 °C and remove supernatant with a multi-channel pipet.

   25. Add 0.2 ml PBS + 0.1% (wt/vol) BSA and mix samples with a multi-channel pipet.

   26. Spin the plate again and repeat the wash with PBS + 0.1% (wt/vol) BSA once more.
       Resuspend each sample in 0.2 ml PBS and keep the plate on ice until the measurement by flow cytometry. Measure the samples in a non-fixed state on the same day.


Data analysis

Note: After the PNS, which contains the phagosomes, has been labeled for OVA and LAMP-1, it is analyzed by flow organellocytometry to determine the kinetics of antigen degradation (level of phagosomal OVA at a given time point) and of the acquisition of lysosomal markers (e.g., LAMP-1). Due to the physical properties and the specific size of microsphere-containing phagosomes, a gating strategy can be applied to measure these parameters simultaneously.

1. Measure the samples by multicolour flow cytometry and apply the following gating strategy:
1. Determine the population of beads and phagosomes in the PNS by measuring OVA-coupled beads alone and apply similar forward scatter (FSC) and side scatter (SSC) settings to your samples. Set a gate on the single particle population (Figure 2A).

2. Exclude surface-bound beads (that are labeled before manual lysis) from subsequent analysis. Include only phagosomes, which are negative for OVA detected by anti-rabbit Alexa 568, by applying a second gate (Figure 2B).

3. The gated population contains single phagosomes, which can be analyzed over time for OVA degradation and LAMP-1 acquisition either simultaneously (Figure 2C) or separately (Figure 2D) by plotting histograms of OVA (detected by anti-rabbit DyLight 633) and LAMP-1 (detected by streptavidin Alexa Fluor 488).
   Note: Depending on the applied fluorophores for antibody labeling and the used flow cytometer, compensation between the different channels might be necessary.

2. Analysis of flow cytometry data was performed using FlowJo software (FlowJo, LLC.). Statistical analysis was performed using Prism 6 software (GraphPad Software, Inc.). Each single experiment needs to be repeated by a sufficient number of independent experiments (at least in triplicate) to draw conclusions from the flow organellocytometry analysis. The data shown in Figure 2 is representative of at least three independent experiments.


   Figure 2. Gating strategy of the applied flow organellocytometry analysis of DC phagosomes. LPS-treated BMDC were allowed to internalize OVA-coated beads at 16 °C and incubated for different chase periods (0 min, 60 min, 120 min) at 37 °C to allow phagosome maturation. Surface-bound, non-internalized beads were stained with anti-OVA and an Alexa 568-coupled secondary antibody. Subsequently, cells were mechanically lysed to release the post-nuclear supernatant (PNS) including bead-containing phagosomes. The PNS was stained for OVA (detected by a DyLight 633-coupled secondary antibody) and LAMP-1 (detected by an Alexa 488-coupled secondary antibody) and analyzed simultaneously by flow cytometry. A. The first gate was set on single beads and single bead-containing phagosomes using forward scatter (FSC) and side scatter (SSC) settings of the labeled PNS. B. In a second gate, non-internalized beads (positive for Alexa 568) were separated from bead-containing phagosomes (negative for Alexa 568). C. Phagosomes were analyzed simultaneously for degradation of OVA and acquisition of LAMP-1 by applying a third gate on the mature, OVA (Dylight 633)-negative and LAMP-1 (Alexa 488)-positive population. D. Alternatively, these two parameters of phagosome maturation can also be analyzed separately and quantified over time.


Notes

1. BMDC are generated from isolated murine bone marrow progenitor cells in GM-CSF-containing medium for 9 days. On the day of experiment, cell surface expression of CD11c should always exceed 85%.

2. The reproducibility of results is highly dependent on homogenous conditions during mechanical breaking and cell lysis. Always control the success of cell lysis by trypan blue staining. Another factor is the phagocytic efficiency of the used cells. Always count cell numbers of your samples to apply comparable bead-to-cell ratios during bead uptake. Do not exceed this ratio, because high numbers of internalized particles will induce cell death and influence the parameters that are measured by flow organellocytometry.

3. Although OVA-coupled particles are used here as phagocytosis model system, other ligands can be applied during bead coupling to investigate the influence of receptor-ligand interactions on phagosome maturation. Some examples are published elsewhere (Hoffmann et al., 2010; Hoffmann et al., 2012).


Recipes

1. Internalization medium
   CO₂-independent medium
   1x glutamax supplement

2. BMDC culture medium
   IMDM
   10% (vol/vol) FBS
   50 μM β-mercaptoethanol
   100 IU/ml penicillin
   100 μg/ml streptomycin
   10% (vol/vol) supernatant from J558 plasmacytoma cells, which was used as GM-CSF source (Winzler et al., 1997)

3. Homogenization buffer
   3 mM imidazole, pH 7.4
   250 mM sucrose
   2 mM PMSF
   1x protease inhibitor cocktail
   2 mM DTT


Acknowledgments

This work was supported by the French National Research Agency through the ‘Investments for the Future’ program (France-BioImaging, ANR-10-INSB-04), ANR-11-LABX-0043 and by the CelTisPhyBio Labex (N- ANR-10-LBX-0038), part of the IDEX PSL (ANR-10-IDEX-0001-02 PSL). We are grateful to the financial support by the European Research Council (2013-AdG No.340046 DCBIOX), by La Ligue Nationale contre le Cancer (EL2014.LNCC/SA), by Fonds Wetenschappelijk Onderzoek (FWO; 1526615N; 11W8415N), by an EMBO long-term fellowship (ALTF 883-2011) and by fellowships of Fondation Recherche Médicale (SPF20101221176) and the omics@VIB program (co-financed by the Marie Curie FP7 People Cofund).
The protocol described here is based on a previously published protocol by our lab (Savina et al., 2010), which was developed further to measure different phagosome maturation parameters in dendritic cells and macrophages.
