Retinal Explant Culture

Materials and Reagents

1. Animals
   We typically use retinas from albino Sprague Dawley rats or mice. Explants can be prepared from animals aged between embryonic day 12 to post-natal day 4.

2. DPBS (Life Technologies, catalog number: 14040 )

3. DMEM (Life Technologies, catalog number: 10569-010 )

4. Fetal bovine serum (FBS) (Wisent, catalog number: 080-450 )

5. Penicillin/streptomycin (Life Technologies, catalog number: 15070 )

6. 70% ethanol

7. Fungizone antimycotic (Life Technologies, catalog number: 15290026 )

8. Sucrose (Sigma-Aldrich, catalog number: S0389 )

9. O.C.T. compound (Somagen, catalog number: 4583 )

10. Explant medium

11. 4% Paraformadehyde (PFA) solution (Electron Microscopy Sciences, catalog number: 15710 ) (see Recipes)

12. 20% sucrose/OCT (1:1) (see Recipes)

13. 20% sucrose solution (see Recipes)


Equipment

1. Millicell organotypic insert (EMD Millipore, catalog number: PICMORG50 )

2. 35 mm dish or 6 well plates

3. 37 °C and 5% CO₂ incubator

4. 100 mm dish

5. 150 mm dish

6. Straight forcep

7. FIne forcep (Fine Science Tools, catalog number: 11252-23 )

8. Curved forcep (Fine Science Tools, catalog number: 91197-00 )

9. Sharp scissor

10. Sharp scapel (Fine Science Tools, catalog number: 10315-12 )

11. Razor blade

12. P1000 pipette

13. CO₂ chamber

14. Cryomold 15 x 15 x 5 mm (VWR International, catalog number: CA60872-016 )


Procedure

Day of Experiment

1. Prepare the explant medium (see Recipes for the preparation of the stock solutions)
   1. Explant medium
      In a 50 ml tube, add: 45 ml of DMEM
      5 ml of fetal bovine serum (FBS)
      500 µl of pen/strep 100x
      50 µl of Fungizone antimycotic
      To equilibrate the medium at the right temperature and pH, put the lid on the 50 ml tube and unscrew ¼ of a turn. Place the tube in the incubator at 37 °C and 5% CO₂ until needed.

2. Preparation of the culture plates
   1. The explants are cultured on a Millicell organotypic insert. We typically use 35 mm dish or 6 well plates to put the insert in.
   2. Fill the dish (or well) with 1.2 ml of equilibrated explants medium and place the insert gently over it with sterile forceps.
   3. Place the dish (or plate) in the incubator at 37 °C and 5% CO₂ until needed.
3. Dissection of the retinas
   Note: The dissection should be carried out under sterile conditions. Spray the working area with 70% ethanol and use a flame. Sterilize all the instruments before use.
   Prepare two 100 mm dish filled with 10 ml of sterile DPBS, one to transfer the heads and the other to dissect the eyes and two 35 mm dish filled with 2 ml of sterile DPBS to collect the retinas.
   1. Collection of the embryos
      1. Euthanize the animal in a CO₂ chamber.

      2. Place the animal on its back and clean the abdomen with 70% ethanol.

      3. Pinch the skin with a straight forcep, lift the skin and muscle and make a V shape opening using scissors on both side of the abdomen, starting from the lower abdomen and cutting all the way up on the side of the animal. Lift the skin and muscle upward to reveal the internal organs and uterus.

      4. Cut out the uterus and transfer it to a 150 mm dish.

      5. Remove the embryos from the uterus and decapitate the heads with sharp scissors.

      6. Transfer the heads to a 100 mm dish filled with DPBS.
   2. Dissection of the retinas
      1. Carefully remove the skin that covers the eye.

      2. Place a curved forcep of both side of the eye and apply a gentle pressure. The eye should pup out.

      3. Pinch the back of the eye and pull.

      4. Transfer the eye in a 100 mm dish filled with DPBS.
         1. With the lens facing downward, secure the eye in position with a fine forceps and remove the optic nerve (Figure 1, steps 1-2).

         2. Introduce the tip of another forceps through the optic nerve head and between the choroid and retina to secure the sclera.

         3. Now that the sclera is secured, you need to gently tear it open with both forceps from the optic nerve head to the cornea to expose the retina and lens (Figure 1, steps 3-4).

         4. Carefully detach the lens and place the retinas in a 35 mm dish filled with DPBS (Figure 1, steps 5-6).

         5. From E18-19 onward, it is required to remove the blood vessels covering the retina to avoid endothelial cell contamination in the culture.

         6. The blood vessels form a reddish membrane overlying the inner face of the retina. The membrane is easily removed by pinching and pulling with fine forceps.

         7. Transfer the retinas in a 35 mm dish filled with DPBS.


      Figure 1. Procedure for retina dissection. Steps 1-5 show the procedure to dissect the retina from the eyeball. Step 6 shows the dissected retina separated from the lens.


4. Preparation of explants
   1. For retinas older than embryonic day 15, cut small pieces of around 5 mm (Figure 2, steps 1-2). For younger retinas, place the whole retina on the insert.

   2. With a razor blade, cut the edge of a P1000 pipette tip to make a lager opening. Transfer the explants from the 35 mm dish to the insert. It doesn’t matter which side of the explants is facing upward on the insert. Gently lay the explants as flat as possible (Figure 2, step 3). Try not to fold or tear the explants as this could lead to defect in the formation of the layers and make the analysis difficult.

   3. Place the dish in the incubator at 37 °C and 5% CO₂. The culture should be left until the retina is fully developed (around post natal day 14 in vivo). For explants started at embryonic day 13, this would mean 20 days in culture. For explants started at post-natal day 0, this would mean 14 days in culture.

   4. The medium should be changed every 3 days by replacing 80% of the medium with fresh one.


      Figure 2. Preparation of the explants. Starting from an entire retina (Step 1), small pieces are cut (Step 2) and placed on the organotypic filter (Step 3).


5. Fixation of the explants
   1. After the desired culture period, remove the insert from the dish and aspirate the culture medium.

   2. Replace it with freshly made 4% PFA. Place the insert back in the dish. Gently add 1 ml of 4% PFA on top of the insert. The PFA solution needs to be at room temperature to help maintain the explant morphology.

   3. Incubate 30 min. Gently rinse 3 times with PBS.


6. Preparation of the explants for cryosectionning
   1. Replace the PBS with a solution of 20% sucrose. Make sure that the explants are well covered. Incubate at 4 °C overnight.

   2. For cryoprotection, fill a small cryomold with a mixture of 20% sucrose/OCT (1:1).

   3. Remove the 20% sucrose solution from the top of the insert, take out the insert from the dish and, using a sharp scapel, cut the membrane around each explant.

   4. Pick the piece of membrane/explant with a fine forceps and place it in the cryomold. Gently push down the explants and lay them at the bottom of the cryomold.

   5. Make sure it is covered with enough 20% sucrose/OCT solution.

   6. Snap-freeze in liquid nitrogen (do not immerse the cryomold in liquid nitrogen, just touch the surface of the nitrogen with the bottom of the mold) and store at -80 °C until ready to section.

   7. The section thickness can vary between 10 and 30 μm depending on the type of analysis needed.


      Figure 3. Micrographs of retinal explant cryosections at 10x (A) or 40x magnification after 14 days in culture. The retina was counterstained with Hoechst to visualize the nuclei. The retinal layers are identified, ONL: outer nuclear layer, INL: inner nuclear layer.


Recipes

1. 4% paraformaldehyde
   10 ml of 16% paraformaldehyde
   26 ml of deionised water
   4 ml of 10x PBS (pH 7.4)

2. 20% sucrose
   Dissolve 20 g of sucrose in 80 ml of 1x PBS (pH 7.4)
   Once in solution, complete the volume to 100 ml with 1x PBS (pH 7.4)

3. 20% sucrose/O.C.T. (1:1)
   20 ml of 20% sucrose solution
   20 ml of O.C.T. compound
   Mix thoroughly


Acknowledgments

Funding for this work was provided by the Canadian Institutes of Health Research and the Foundation Fighting Blindness Canada. This protocol was adapted from procedures published in Kechad et al. (2012) and Elliott et al. (2008). The authors wish to thank members of the Cayouette lab, past and present, for continuous support and improvements on the protocol over the years.

References

1. Cayouette, M., Barres, B. A. and Raff, M. (2003). Importance of intrinsic mechanisms in cell fate decisions in the developing rat retina. Neuron 40(5): 897-904.

2. Cayouette, M. and Raff, M. (2003). The orientation of cell division influences cell-fate choice in the developing mammalian retina. Development 130(11): 2329-2339.
3. Elliott, J., Jolicoeur, C., Ramamurthy, V. and Cayouette, M. (2008). Ikaros confers early temporal competence to mouse retinal progenitor cells. Neuron 60(1): 26-39.

4. Kechad, A., Jolicoeur, C., Tufford, A., Mattar, P., Chow, R. W., Harris, W. A. and Cayouette, M. (2012). Numb is required for the production of terminal asymmetric cell divisions in the developing mouse retina.  J Neurosci 32(48): 17197-17210.
