Materials and Reagents

1. Species
   Three Chlorella species were used: C. vulgaris, isolated from soil samples of Livingston Island, the South Shetland Archipelago, Antarctic; C. vulgaris strain 8/1, isolated in 1968 from thermal springs in the region of Rupite, Bulgaria, and cultivated in our laboratory since 1975 and Chlorella kesslery a mesophile, from the Trebon collection.
   Cultivation
   Chlorella species were cultivated on TAP (Tris Acetate Phosphate) medium under continuous light of 60 μmol/m²/s and a temperature of 23 °C ± 0.1 °C in a Phytotron GC 400 growth chamber. The species were cultivated at this temperature because it is well known, that eurythermal algae, could be grown at a wide range of temperatures.

2. Rabbit polyclonal antibody HSP70B cytoplasmic (Agrisera, catalog number: AS06 175 )

3. Goat anti-rabbit IgG(H&l) HRP conjugated (Agrisera, catalog number: AS09 602 )

4. Coomassie brilliant blue G 250

5. Orthophosphoric acid (Valerus, catalog number: N 4420 )

6. Trichloroacetic acid (TCA)

7. Bovine serum albumin (BSA) (Applichem GmbH, catalog number: 1391 0025 )

8. Albumin fraction V (pH 7.0)

9. Medium Pure Nitrocellulose (NCM) (0.45 μm) (Bio-Rad Laboratories, catalog number: 162-0115 )

10. Filter paper

11. Sponge

12. 4CN (4-chloro-naphthol) (Bio-Rad Laboratories, catalog number: N170-6535 )

13. N,N′ N′ Tetramethylethylendiamine (TEMED) (Alfa Aesar, catalog number: N12536 )

14. Laemmli sample buffer (see Recipes)

15. Reagent of Bradford (see Recipes)

16. 5x Laemmli buffer (see Recipes)

17. Running buffer (see Recipes)

18. Transfer buffer (see Recipes)

19. SDS-PAGE gel (see Recipes)

20. 30% Acrylamide/N,N’-methylenebisacrylamide (AA/MBA) (see Recipes)

21. 10% SDS (see Recipes)

22. 10% Ammonium Persulfate (see Recipes)

23. 1.5 M Tris HCl buffer (pH 8.8) (see Recipes)

24. 1.0 M Tris HCl buffer (pH 6.8) (see Recipes)

25. 4 M NaCl (see Recipes)

26. 1.0 M Tris HCl buffer (pH 7.5) (see Recipes)

27. 20% Tween 20 (see Recipes)

28. Blocking buffer (see Recipes)

29. Staining solution (see Recipes)

30. 5% CH₃COOH (see Recipes)

31. Washing solution (see Recipes)

32. 50 mM TBS-T buffer (see Recipes)

33. HRP color development solution (see Recipes)


Equipment

1. Motor

2. Silica  quartz sand 0.6 mm (Valerus, catalog number: N 1760 )

3. Centrifuge (Sigma-Aldrich, model: 1-15 K)

4. Electrophoresis chamber Transfer unit Hoefer miniVE electrophotesis and electrotransfer unit (Hoefer, model: SE300-10A-1.0 )

5. Mini Rocker Shaker MR-1


Software

1. Image J program

Procedure
