Quantitation of Cytochromes b₅₅₉, b₆, and f, and the Core Component of Photosystem I P₇₀₀ in Cyanobacterial Cells

量化蓝藻细胞中的细胞色素b559、b6和f以及光和体系的核心成分I P700

Motohide Aoki

Mikio Tsuzuki

Norihiro Sato email

发布: 2016年11月05日第6卷第21期 DOI: 10.21769/BioProtoc.1991 浏览次数: 8178

评审: Maria Sinetovalina YinFanglian He

PDF

Q&A

引用

Cited by

参见作者原研究论文

The authors used this protocol in:

Cover of Plant & Cell Physiology, featuring study using the protocol.

Aug 2015

实验方案合集

Cell Imaging - A Special Collection for Cell Bio 2023

相关实验方案

基于Azo-Xylan及其变体的Endo-1,4-β-D-木聚糖酶活性检测方法

Luca Bombardi [...] Salvatore Fusco

2025年04月20日 1193 阅读

嗜热栖热菌CRISPR Cas6的异源表达与纯化方法

Junwei Wei [...] Yingjun Li

2025年07月20日 1329 阅读

测定丙酮酸激酶动力学的优化酶偶联分光光度法

Saurabh Upadhyay

2025年08月20日 1230 阅读

Abstract

Cytochrome (Cyt) b₅₅₉, an important and essential core component of photosystem II in the photosynthetic electron transport system, is a heme-bridged heterodimer protein composed of an alpha subunit (PsbE) and a beta subunit (PsbE), and its reduced form has an absorption maximum in the α-band at 559 nm. The amounts of Cyt b₅₅₉ can be determined by spectrophotometrical measurement of reduced minus oxidized difference spectra that are normalized with absorbance of isosbestic point at 580 nm. The authors use differential extinction coefficients of Cyt b₅₅₉ [Δε_{(559-580 nm)} = 15.5 mM^-1·cm^-1], which have been reported by Garewal and Wasserman (1974). In addition to the Cyt b559, this procedure can be used for quantitation of Cyt b₆ and Cyt f, the subunits of the Cyt b₆/f complex, and P₇₀₀, one of the core components of photosystem I. This protocol, which is adapted from Fujita and Murakami (1987), is used in a cyanobacterium, Synechococcus elongatus PCC 7942, and also in other cyanobacterial strains including Synechocystis sp. PCC 6803.

Materials and Reagents

50 ml polypropylene centrifuge tubes with conical bottom (Corning, Falcon^®, catalog number: 352070 )
20 ml standard glass test tubes (Thermo Fisher Scientific, Fisher Scientific, catalog number: S63289 )
10 ml Oak Ridge high-speed PPCO centrifuge tubes (Thermo Fisher Scientific, Thermo Scientific^TM, catalog number: 3119-0010 )
1.5 ml polypropylene microcentrifuge tubes (Eppendorf, catalog number: 0030125150 )
0.20 µm cellulose acetate membrane filter, sterile (Toyo Roshi Kaisha, catalog number: 25CS020AS )
Micro spatula
Synechococcus elongatus PCC 7942 (http://cyanobacteria.web.pasteur.fr/)
BG11 as a culture medium (Rippka et al., 1979)
0.1 mm diameter Zirconia/Silica beads (BioSpec, catalog number: 11079101z )
Sodium ascorbate (Sigma-Aldrich, catalog number: A7631 )
Sodium hydrosulfite (Sigma-Aldrich, catalog number: 157953 )
Methanol (Wako Pure Chemical Industries, catalog number: 139-13995 )
HEPES (Dojindo Molecular Technologies, catalog number: GB10 )
Sodium hydroxide (NaOH) (Wako Pure Chemical Industries, catalog number: 198-13765 )
Sodium chloride (NaCl) (Wako Pure Chemical Industries, catalog number: 191-01665 )
Tricine (Dojindo Molecular Technologies, catalog number: GB19 )
Hydrochloric acid (HCl) (Wako Pure Chemical Industries, catalog number: 080-01066 )
Potassium ferricyanide (III) (Sigma-Aldrich, catalog number: 702587 )
Hydroquinone (Sigma-Aldrich, catalog number: H9003 )
HN buffer (see Recipes)
50 mM tricine buffer (pH 7.5) (see Recipes)
100 mM potassium ferricyanide solution (see Recipes)

Equipment

Vortex mixer (Scientific Industries, model: Vortex-Genie 2 )
Tabletop centrifuge (KUBOTA, model: 5220 ) equipped with ST-720M swing rotor (16 x 50 ml)
High speed refrigerated centrifuge (KUBOTA, model: 7700 ) equipped with RA-150 rotor (12 x 12 ml)
High speed refrigerated micro centrifuge (Tomy, model: MX-301 ) equipped with 1.5 ml/2.0 ml rotor
Ultrasonic cell disruptor (Branson, model: Sonifier SFX250 ) equipped with tapered microtip
Spectrophotometer (Beckman Coulter, model: DU 640 )
300 µl micro cuvette, 10 mm optical pathlength (Hellma, catalog number: 105-QS )
PTFE coated nickel stainless steel micro spatula (Kokugo, catalog number: 101-378-51 )

Procedure

English

中文翻译

文章信息

版权信息

如何引用

Aoki, M., Tsuzuki, M. and Sato, N. (2016). Quantitation of Cytochromes b₅₅₉, b₆, and f, and the Core Component of Photosystem I P₇₀₀ in Cyanobacterial Cells. Bio-protocol 6(21): e1991. DOI: 10.21769/BioProtoc.1991.
