The Application of Quercetin to Study the Effect of Hsp70 Silencing on Plant Virus Infection in Nicotiana benthamiana Plants

采用槲皮素研究本氏烟草植株中Hsp70沉默对植株病毒感染的影响

Matthaios M. Mathioudakis Matthaios M. Mathioudakis
Ioannis Livieratos Ioannis Livieratos

发布: 2015年12月05日第5卷第23期 DOI: 10.21769/BioProtoc.1675 浏览次数: 8253

评审: Zhaohui LiuAnonymous reviewer(s)

download pdf 下载 PDF 下载 PDF
ask Q&A
引用
收藏
Cited by

参见作者原研究论文

The authors used this protocol in:

Cover of Molecular Plant Microbe Interactions, featuring study using the protocol.

Dec 2014

Presubmission Inquiry

实验方案合集

专注于特定技术或应用的、详细的、经过同行评审的实验方案合集

Cancer Research
Immunology
Developmental Biology
Microbiology
Neuroscience
Cell Imaging - A Special Collection for Cell Bio 2023
查看更多 more

相关实验方案

iSLK细胞系的常规维护与KSHV再活化操作

iSLK细胞系的常规维护与KSHV再活化操作

Ariana C. Calderón-Zavala [...] Ekaterina E. Heldwein

2025年06月05日 997 阅读

诱导型HIV-1库削减检测（HIVRRA）：用于评估外周血单个核细胞中HIV-1潜伏库清除策略毒性与效力的快速敏感方法

诱导型HIV-1库削减检测（HIVRRA）：用于评估外周血单个核细胞中HIV-1潜伏库清除策略毒性与效力的快速敏感方法

Jade Jansen [...] Neeltje A. Kootstra

2025年07月20日 1283 阅读

基于转化相关重组的酵母体系组装与诱变人冠状病毒OC43基因组

基于转化相关重组的酵母体系组装与诱变人冠状病毒OC43基因组

Brett A. Duguay and Craig McCormick

2025年08月20日 1118 阅读

Abstract

Pepino mosaic virus (PepMV) is a mechanically-transmitted pathogen affecting tomato plants worldwide. Like with other plant viruses (Verchot, 2012), the heat shock cognate protein 70 homolog (Hsc70) was identified as an interactor of the PepMV coat protein (CP) (Mathioudakis et al., 2012). Here, we describe a pharmacological approach to silence Hsp70 in plants using quercetin (Mathioudakis et al., 2014), an Hsp70 protein expression flavonoid inhibitor (Hosokawa et al., 1990; Manwell and Heikkila 2007). In the case of Hsp70, this methodology represents a faster and easier approach than silencing of Hsp70 by reverse genetics assays, such as VIGS methodology. Fully expanded leaves of 2 to 3 weeks old Nicotiana benthamiana plants were infiltrated, using a syringe, with either quercetin (dissolved in DMSO) or DMSO (control plants). The plants were mechanically inoculated with PepMV virus inocula. The accumulation of Hsp70 and PepMV were analyzed on local leaves by immunoblot analysis 4 days post inoculation.

Materials and Reagents

  1. 1 ml syringe without a needle (BD, Nipro, catalog number: SY3 1 C100U ET )
  2. Mortar and pestles (Carl Roth GmbH + Co., catalog number: XL96.1 and XP01.1 )
  3. Pelet pestles (Nippon Genetics, catalog number: NG006 )
  4. 13 ml round base tubes (SARSTEDT AG & Co, catalog number: 62.515.006 )
  5. 1.5 ml microtubes (SARSTEDT AG & Co, catalog number: 72.690.001 )
  6. Nicotiana benthamiana leaves from 2 to 3 weeks old seedlings
  7. PepMV-Sp13 isolate infected material
  8. Quercetin hydrate (Sigma-Aldrich, catalog number: 337951 )
  9. Dimethyl sulfoxide (DMSO) (AppliChem GmbH, catalog number: A3009 )
  10. 10 mM Sodium carbonate (Na2CO3) (Sigma-Aldrich, Riedel-de Haen, catalog number: 31432 )
  11. Sodium dihydrogen phosphate monohydrate (0.5 M, pH 7.0) (AppliChem GmbH, catalog number: A3559 )
  12. Sodium phosphate dibasic (Na2HPO4) (Sigma-Aldrich, catalog number: S0876 )
  13. Potassium dihydrogen phosphate (KH2PO4) (Merck Millipore Corporation, catalog number: 104873 )
  14. Potassium chloride (KCl) (Sigma-Aldrich, Riedel-de Haen, catalog number: 31248 )
  15. Sodium Chloride (NaCl) (AppliChem GmbH, catalog number: A1149 )
  16. Magnesium Chloride 6-hydrate (MgCl2) (AppliChem GmbH, catalog number: A4425 )
  17. Silicon carbide (carborundum) 400 mesh (Sigma-Aldrich, catalog number: 357391 )
  18. Bromophenol blue (Sigma-Aldrich, catalog number: B-8026 )
  19. Coomassie Brilliant Blue (AppliChem GmbH, catalog number: A1092 )
  20. Glycerol (Sigma-Aldrich, catalog number: G6279 )
  21. Tris ultrapure (1.5 M, pH 8.8; 1 M, pH 6.8) (AppliChem GmbH, catalog number: A1086 )
  22. β-mercaptoethanol (Sigma-Aldrich, catalog number: M3148 )
  23. 30% 37.5:1 Acrylamide/Bis solution (Bio-Rad Laboratories, AbD Serotec®, catalog number: 161-0158 )
  24. 10% Ammonium persulfate (APS) (AppliChem GmbH, catalog number: A2941 )
  25. N, N, N´, N´-tetramethylethylenediamine (TEMED) (AppliChem GmbH, catalog number: A1148 )
  26. 10% Sodium dodecyl sulfate (SDS) (AppliChem GmbH, catalog number: A2263 )
  27. Glycine (AppliChem GmbH, catalog number: A1067 )
  28. Phenylmethanesulfonyl fluoride (PMSF) (Sigma-Aldrich, catalog number: P7626 )
  29. Methanol (Thermo Fisher Scientific, catalog number: M/4000/17 )
  30. Acetic acid (Sigma-Aldrich, catalog number: 33209 )
  31. PepMV CP polyclonal antibody (Neogen/Adgen Phytodiagnostics, catalog number: 1127-01 )
  32. HSP70 monoclonal antibody (Enzo Life Sciences, Stressgen, catalog number: N27F3-4 )
  33. Anti-rabbit IgG, Alkaline phosphatase-conjugated antibody (Promega Corporation, catalog number: S3731 )
  34. Anti-mouse IgG, Alkaline phosphatase-conjugated antibody (Promega Corporation, catalog number: S3721 )
  35. BCIP/NBP Color Development Substrate (Promega Corporation, catalog number: S3771 )
  36. PVDF membrane, Westran Clear Signal (Thermo Fisher Scientific, Whatmann, catalog number: 10485289 )
  37. Tween-20 (Sigma-Aldrich, catalog number: P2287 )
  38. Phosphate buffer saline (PBS) (see Recipes)
  39. Protein extraction buffer (see Recipes)
  40. 4x Laemmli buffer (see Recipes)
  41. SDS-PAGE buffers: Separation and Stacking gel buffers (see Recipes)
  42. Western Blot buffers: Running, Transfer, Wash and Detection buffers (see Recipes)

Equipment

  1. Plant growth chamber (25 °C, light:dark =16:8 h)
  2. Biofuge stratos highspeed table centrifuge (Thermo Fisher Scientific, Heraeus, catalog number: 75005282 )
  3. Fixed angle rotor #3334 (Thermo Fisher Scientific, Heraeus, catalog number: 75003334 )
  4. Fixed angle microliter rotor #3332 (Thermo Fisher Scientific, Heraeus, catalog number: 75003332 )
  5. Mini-PROTEAN 3 Cell Electrophoresis System (Bio-Rad Laboratories, AbD Serotec®, catalog number: 165-3301 )
  6. Mini Trans-Blot Electrophoretic Transfer Cell apparatus (Bio-Rad Laboratories, AbD Serotec®, catalog number: 170-3930 )
  7. Power Pack Supply model 200/2.0 (Bio-Rad Laboratories, AbD Serotec®, catalog number: 165-4761 )
  8. Western blot membranes were visualized using the Gel DocTM XR Molecular Imager & System (Bio-Rad Laboratories, AbD Serotec®, catalog number: 170-8195 EDU )
  9. Julabo Water-bath TW12 (Sigma-Aldrich, catalog number: Z615498 )
    Note: Pricing & availability is not currently available.

Software

  1. Quantification of the band intensity as absorbance units was conducted by Quantity One analysis software (Bio-Rad Laboratories, AbD Serotec®, catalog number: 170-9600)

Procedure

English
中文翻译

文章信息

版权信息

© 2015 The Authors; exclusive licensee Bio-protocol LLC.

如何引用

Mathioudakis, M. M. and Livieratos, I. (2015). The Application of Quercetin to Study the Effect of Hsp70 Silencing on Plant Virus Infection in Nicotiana benthamiana Plants. Bio-protocol 5(23): e1675. DOI: 10.21769/BioProtoc.1675.
