Induced Germinal Center B Cell Culture System

Reviewed by
Julia Jellusova Julia Jellusova
How to cite Favorites Q&A Share your feedback Cited by

In this protocol

Original research article

A brief version of this protocol appeared in:
Nature Immunology
Sep 2018



Abstract

The germinal center (GC) is the site where B cells undergo clonal expansion, affinity-based selection, and differentiation into memory B cells or plasma cells. It has been difficult to elucidate regulatory mechanisms for the dynamic GC B cell maturation and differentiation, partly because experimental manipulation of GC B cells in vivo has been limited and no in vitro system has been available that resembles B cell reaction in GC. Here we describe the protocol for a culture system named “induced GC B (iGB) culture system” which can induce massive expansion of B cells that exhibit GC B cell-like phenotype, and thus it mimics the GC reaction. This protocol can be useful to elucidate the molecular mechanisms of GC B cell differentiation.

Keywords: iGB cell, 40LB cell, CD40L, BAFF, Germinal center, Memory B cell, B cell culture

Background

In the field of T cell immunology, in vitro culture systems that allow differentiation of naive T cells toward specific effector T cell subsets have been widely used to study molecular mechanisms for the T-cell differentiation. However, there has been no practical culture system to effectively induce expansion of B cells with high viability and differentiation towards GC B cells. To study the GC B cell biology in vitro, we have developed a novel B-cell culture system that mimics GC B-cell reaction (Nojima et al., 2011). For this system, we generated a feeder cell line named 40LB, a Balb/c 3T3 cell line expressing exogenous CD40-ligand (CD40L) and B-cell activating factor (BAFF) that together promote B cell proliferation and survival. When naive B cells are cultured with IL-4 for the first 4 days and then with IL-21 for the second 4 days on the feeder cells, B cells proliferate exponentially up to 10,000 fold, efficiently undergo isotype switching to IgG1 and IgE, the Th2 related isotypes, and express GC B-cell markers such as GL7 and Fas. Thus, we termed the B cells propagated in this system in-vitro-induced GC B (iGB) cells, and this system the iGB cell culture system. Compared to simply stimulating B cells with anti-CD40 antibody and BAFF with IL-4, which can induce only a 20-fold expansion of B cells in 6 days and less efficient isotype switching, iGB cell culture system is very useful. The iGB cell culture system have been widely used to study B cell biology, such as GC B cell expansion and differentiation, signaling from various receptors, immunoglobulin gene class-switch recombination, and so on (Fukao et al., 2014; Haniuda et al., 2016). The iGB cells not only phenotypically resemble genuine GC B cells but they functionally mimic some aspects of GC B cells: the iGB cells after the primary culture with IL-4 differentiate in vivo into memory-like B cells when transferred into mice, whereas those after the secondary culture with IL-21 differentiate in vivo into plasma cells that are relatively long-lived (Nojima et al., 2011; Moutai et al., 2014). Hence the iGB cell culture system is also applicable for the studies of molecular mechanisms for their differentiation into memory B cells or long-lived plasma cells, and their responses (Takatsuka et al., 2018). Here, we describe a detailed protocol for the iGB cell culture system.

Materials and Reagents

  1. 50 ml tube (Thermo, catalog number: 339652)
  2. 15 ml tube (Thermo, catalog number: 339650)
  3. 5 ml round-bottom tube (Falcon, catalog number: 352054)
  4. 10 cm dish (Falcon, catalog number: 353003)
  5. 6-well plate (Costar, catalog number: 3516)
  6. 12-well plate (Costar, catalog number: 3513)
  7. 26 G needle (Terumo, catalog number: NN-2613S)
  8. 10 ml syringe (Terumo, catalog number: SS-10SZ)
  9. Cryovial (Thermo, catalog number: 375418)
  10. Frosted glass slides (Matsunami, catalog number: S2226)
  11. MACS LS Columns (Miltenyi Biotec, catalog number: 130-042-401)
  12. 100 µm mesh (TGK, catalog number: N—No.200HD)
  13. 40 µm mesh (TGK, catalog number: N—No.355T)
  14. 40LB cells: BALB/c3T3 cells (provided by RIKEN BRC) stably expressing mouse CD40L and mouse BAFF (Nojima et al., 2011)
  15. D-MEM (high glucose, WAKO, catalog number: 044-29765)
  16. Fetal bovine serum (FBS, see Notes)
  17. Trypsin-EDTA (WAKO, catalog number: 204-16935)
  18. Penicillin-streptomycin (Gibco, catalog number: 15140-122)
  19. RPMI-1640 (WAKO, catalog number: 189-02025)
  20. HEPES (Dojindo, catalog number: 346-08235)
  21. 2-mercaptoethanol (2-ME, Gibco, catalog number: 21985-023)
  22. NaCl (WAKO, catalog number: 195-01663)
  23. KCl (WAKO, catalog number: 163-03545)
  24. Na2HPO4 (WAKO, catalog number: 196-02835)
  25. KH2PO4 (WAKO, catalog number: 169-04245)
  26. EDTA (Dojindo, catalog number: 345-01865)
  27. Biotinylated anti-CD43 (BD Pharmingen, clone: S7, catalog number: 553269)
  28. Biotinylated anti-Ter119 (Biolegend, clone: TER-119, catalog number: 116204)
  29. Biotinylated anti-CD4 (Biolegend, clone: GK1.5, catalog number: 100404)
  30. Biotinylated anti-CD8 (Biolegend, clone: 53-6.7, catalog number: 100704)
  31. Biotinylated anti-CD49b (Biolegend, clone: DX5, catalog number: 108904)
  32. Biotinylated anti-H-2Kd (Biolegend, clone: SF1-1.1, catalog number: 116604)
  33. Biotinylated anti-CD138 (Biolegend, clone: 281-2, catalog number: 142512)
  34. Streptavidin Particles Plus-DM (BD, IMag, catalog number: 557812)
  35. Recombinant mouse IL-4 (PeproTech, catalog number: 214-14)
  36. Recombinant mouse IL-21 (PeproTech, catalog number: 210-21)
  37. 3T3 medium (see Recipes)
  38. B cell medium (BCM) (see Recipes)
  39. Phosphate-buffered saline (PBS) (see Recipes)
  40. MACS buffer (see Recipes)
  41. Antibody cocktail for B cell isolation (for one spleen) (see Recipes)
  42. Antibody cocktail for feeder cell depletion (for cells) (see Recipes)

Equipment

  1. Pipettes
  2. Autoclave
  3. 37 °C water bath
  4. CO2 incubator (Panasonic, catalog number: MCO-170AIC-PJ)
  5. Laminar flow hood (SANYO, Bio clean bench)
  6. Mr. Frosty (Thermo, catalog number: 5100-0001)
  7. -80 °C freezer
  8. Liquid nitrogen storage tank
  9. Cell separation Magnet (BD IMag, catalog number: 552311)
  10. Centrifuge (Kubota, 4000, 5911, 6200)
  11. MACS MultiStand (Miltenyi Biotec, catalog number: 130-042-303)
  12. MidiMACS Separator (Miltenyi Biotec, catalog number: 130-042-302)

Procedure

A schematic overview of the experimental procedure is shown in Figure 1.


Figure 1. A schematic illustration of the procedure for iGB cell culture system

  1. Propagation of 40LB cells and preparation of feeder layer of 40LB cells
    40LB feeder cells are typically cultured and maintained with 10 ml of 3T3 medium in a 10 cm dish at 37 °C, 5% CO2. Passage the 40LB cells every 3 days with 6-fold dilutions and keep in culture up to one month, as described below. After one month or so, restart the culture from a frozen stock. The following protocol is for the culture using 10 cm dishes. Change the volume of solutions in proportion to the bottom area of the plate (well) to use, as shown by examples in Table 1.
    1. Thaw a frozen 1 ml 40LB cell stock and dilute the content with 12 ml of 3T3 medium (see Recipes).
    2. Centrifuge cells at 270 x g for 5 min at 4 °C.
    3. Discard the supernatant and resuspend the cells in 10 ml of 3T3 medium by pipetting, and seed all cells into a 10 cm culture dish.
    4. Culture cells at 37 °C, 5% CO2 for 1-2 days until they reach 70%-80% confluence.
    5. Remove the medium from the cell culture dish, and rinse it with 2 ml of PBS (see Recipes).
    6. Discard the PBS, add 1 ml of Trypsin-EDTA and leave the dish at room temperature until cells get dispersed (it takes about 1-3 min).
    7. Add 3 ml of 3T3 medium and gently pipette up and down to completely detach the cells.
    8. Transfer the cell suspension to a tube and centrifuge at 270 x g for 5 min at 4 °C.
    9. Discard the supernatant and resuspend the cells in the desired volume of 3T3 medium.
    10. For passage, dilute cell suspension 6-fold from Step A9, seed cells into 10 cm culture dishes and culture cells at 37 °C, 5% CO2 for 3 days.
    11. For irradiation, seed an appropriate number of 40LB cells from Step A9 to the desired plate (see Table 1), and allow cells at least 12 h to attach the plate. Alternatively, irradiate the harvested 40LB cells in a tube, then seed them onto plates, and culture them for at least 12 h until the 40LB cells attach to the plates and completely spread out.
    12. Irradiate the cells with 80 Gy of γ-ray to stop proliferation.
    13. For cell stock, resuspend the cell pellet from Step A9 in ice-cold 20% FBS and 10% DMSO (~2 x 106 cells per ml), add 1 ml of cell suspension to each cryovial, place the vials in a Mr. Frosty, then place the cells in a -80 °C deep freezer for 24 h. After 24 h, transfer the vials to a liquid nitrogen storage tank.

      Table 1. Plate type, cell number to seed and volume of solutions


  2. Isolation and purification of B cells from mouse spleen for the iGB cell culture
    Keep cells on ice or 4 °C, and use pre-chilled solutions. The following is the protocol for one spleen.
    1. Take a spleen from a C57BL/6 mouse and put the spleen in a 10 cm dish.
    2. Inject 10 ml of MACS buffer (see Recipes) inside the spleen using a 26 G needle and 10 ml syringe, in order to extract splenocytes, and then gently disrupt the remaining spleen capsular using a pair of frosted glass slides.
    3. Transfer the cell suspension with a pipette to a tube through a 100 µm mesh.
    4. Centrifuge at 370 x g for 6 min.
    5. Discard the supernatants, resuspend the cells with 10 ml of MACS buffer and count the cell number.
    6. Discard the supernatant, add 100 µl of antibody cocktail for B cell isolation (see Recipes) per 108 cells and gently pipette up and down to suspend the cells completely.
    7. Incubate for 20 min on ice.
    8. Wash the cells twice by adding 10 ml of MACS buffer with centrifugation (370 x g for 6 min) at each step.
    9. Discard the supernatants, add 50 µl of Streptavidin Particles Plus-DM per 108 cells and gently pipette up and down to suspend the cells completely.
    10. Incubate the cells for 20 min on ice.
    11. Place two 5 ml round-bottom tubes onto the IMag cell separation Magnet.
    12. Resuspend cells with 2 ml of MACS buffer and transfer into the first tube on the magnet.
    13. Wait for 5 min until the labeled cells attach to the wall of the tube beside the magnet.
    14. Collect unbound cells from the first tube and transfer it to the second tube.
    15. Detach the first tube and resuspend the attached cells in the first tube with a new 2 ml of MACS buffer, and then place the tube back onto the magnet and leave it for 5 min.
    16. Collect unbound cells from the second tube and transfer it to the collection tube.
    17. Repeat Steps B13-B15 once more.
    18. Collect unbound cells from the first tube, transfer it to the second tube and leave it for 5 min.
    19. Collect unbound cells from the second tube and transfer it to the collection tube.
    20. Centrifuge the whole collected cells at 370 x g for 6 min.
    21. Place an LS column onto a MidiMACS Separator attached to MACS MultiStand, and place 40 µm mesh on the top of the LS column.
    22. Rinse the column with 2 ml of MACS buffer.
    23. Discard the supernatants from Step B19 and resuspend the cells with 1 ml of MACS buffer.
    24. Apply the cell suspension onto the LS column through the 40 µm mesh and allow all the suspension to pass through the column.
    25. Wash the column 3 times with 1 ml of MACS buffer each.
    26. Wash the column once with 3 ml of MACS buffer.
    27. Collect all the effluent and centrifuge at 370 x g for 6 min.
    28. Discard the supernatants, resuspend the cells with 10 ml of B cell medium (BCM, see Recipes) and count the cell number.
      Note: The expected B cell number from one spleen is 2 x 107-5 x 107 cells.
    29. Check the purity of isolated B cells using flow cytometry. Use fluorochrome-conjugated antibodies against B cell markers such as CD19 and B220. The purity of B cells is usually more than 97%.
      Note: Alternatively, positively sorted B cells using MACS or FACS can be used for the culture. B cells from peripheral blood or other lymphoid organs such as lymph nodes can also be used.

  3. iGB cell culture
    Use pre-warmed buffer and medium. The following protocol is for the culture using a 10 cm dish.
    Note: After the B cells start to proliferate and become ‘iGB cells’, the iGB cells should be treated at room temperature during all procedures such as centrifugation, antibody staining, iMag, MACS or flow cytometry, etc. iGB cells tend to die on ice.
    1. Remove culture medium of irradiated feeder cells from the 10 cm dish and add 35 ml of BCM supplemented with IL-4 (final concentration is 1 ng/ml).
    2. Add 5 ml of BCM containing an appropriate number of the isolated B cells (see Table 1) and culture at 37 °C, 5% CO2 for 4 days (Figure 2).


      Figure 2. Bright-field microscopy of the iGB cells and a 40LB layer. A and B. iGB cells on a feeder layer after culturing with IL-4 for 4 days. (A) 4x magnification, (B) 20x magnification. C. 40LB feeder layer after 80 Gy irradiation at 4x magnification.

    3. To harvest cells, carefully remove medium from the surface down to the level about 0.5 cm above the bottom and transfer the remaining medium to a collection tube (the volume of remaining medium is about 10 ml).
    4. Add 4 ml of MACS buffer and leave dish at room temperature until cells begin to get dispersed (it takes about 3-5 min).
    5. Gently shake the dish to detach the cells and collect them to the tube.
    6. Rinse the plate with 5 ml of MACS buffer and collect the medium into the tube. Repeat once more.
    7. Centrifuge all the collected cells at 370 x g for 5 min at room temperature.
    8. Discard the supernatants and disrupt the cell pellet by gentle shaking. Resuspend the cell pellet with 10 ml of B cell medium and count the cell number. iGB cells are distinguishable as the cells smaller than the 40LB cells.
      Note: The expected iGB cell number from a 10 cm dish is 2 x 107-4 x 107, and the viability of iGB cells exceeds 90%.
    9. To culture the cells sequentially, seed appropriate number of the iGB cells onto a new irradiated feeder layer and culture them as described in Step C1 with an appropriate cytokine.
      Note: Primary cultured iGB cells can be re-expanded on the new feeder layer with 10 ng/ml IL-21 (or IL-4 which will promote further switching to IgE), as described in the original article (Nojima et al., 2011). For this, put the whole harvested cells including the feeder cells onto the new feeder layer, adjusting the number of iGB cells as desired. For example, primary iGB cells on Day 4 can be seeded, to culture with IL-21, at 5 x 105 (for 3 more days) or 5 x 104 (for 4 more days) per 10 cm dish. In the secondary culture with IL-21, the growth rate of iGB cells is difficult to predict, thus change the medium when it begins to turn yellowish. In our experience, the expected expansion factor of iGB cell during the secondary culture is 100-300 fold (in 4 days), and the viability of iGB cells always exceeds 70%. The secondary culture can be continued for at least 6 days without feeder renewal.

  4. Feeder cell depletion
    It is desirable to remove feeder cells from harvested cells of the iGB cell culture when they are transferred into mice or analyzed at a molecular level. This depletion protocol is for cells from one 10 cm dish. Use pre-warmed buffer and medium.
    1. Harvest cells as in Steps C3-C7.
    2. Discard the supernatants and disrupt the cell pellet with gentle shaking. Add 260 µl of an antibody cocktail for feeder cell depletion (see Recipes) and gently pipette up and down to suspend the cells completely. For cells from 1 well of a 6-well or 12-well plate, use 1/6 or 1/12 volume, respectively, of diluted antibody with the same concentration.
    3. Incubate for 20 min at room temperature.
    4. Wash the cells twice by adding 10 ml of MACS buffer with centrifugation (370 x g for 5 min at room temperature) at each step.
    5. Discard the supernatant and disrupt the cell pellet with gentle shaking. Add 50 µl of Streptavidin Particles Plus-DM and 100 µl of MACS buffer, and then gently pipette up and down to suspend the cells completely.
    6. Incubate for 20 min at room temperature.
    7. Apply to iMag and MACS procedure as described in Steps B10-B24.
    8. Collect all the effluent and centrifuge at 370 x g for 5 min at room temperature.
    9. Resuspend the collected cells in 10 ml of an appropriate medium or buffer and count the cell number.

Notes

An FBS lot check is required, as lot-specific differences in FBS influence the cell growth, class switching and the generation of the iGB cells. Indeed, only ~30% of the lots we tested worked well. When we select the FBS lot for iGB cell culture, we usually use the following parameters: 1) Cell expansion factor during the primary culture with IL-4 (more than 60-fold in 96 h) and the secondary culture with IL-21 (more than 100-fold in 96 h). 2) FACS profiles after the primary and the secondary culture: efficient class switching to IgG1 and IgE (but no more than 50% IgE+ cells) and homogeneous expression of GL7 and Fas, and minimal differentiation to CD138+ cells after the primary culture. Most of the FBS lots can support the expansion and survival of 40LB cells.

Recipes

Note: When preparing the following solutions, mix all of components in a sterile hood.

  1. 3T3 medium
    D-MEM supplemented with 10% heat-inactivated fetal bovine serum (FBS)
    100 U/ml penicillin
    100 µg/ml streptomycin
    Store at 4 °C , Shelf life: 2 months from the date of manufacture
    Note: FBS can be heat-inactivated by incubation at 56 °C for 30 min.
  2. B cell medium (BCM)
    RPMI-1640 supplemented with 10% heat-inactivated FBS
    10 mM HEPES-NaOH pH 7.5
    5.5 x 10-5 M 2-ME
    100 U/ml penicillin
    100 µg/ml streptomycin
    Store at 4 °C, Shelf life: 2 months from the date of manufacture
  3. Phosphate-buffered saline (PBS)
    1. Stock (20x): dissolve 160 g NaCl, 4 g KCl, 23 g Na2HPO4 and 4 g KH2PO4 in MilliQ water
    2. Fill up to 1 L with MilliQ water
    3. Dilute 1:20 with MilliQ water and autoclave
    Store at 4 °C, Shelf life: 1 year from the date of manufacture
  4. MACS buffer
    1. Make 500 ml of PBS supplemented with 2 mM EDTA and autoclave
    2. Add 12.5 ml of 0.22 µm-filtered 20% BSA in PBS
    Store at 4 °C, Shelf life: 6 months from the date of manufacture
  5. Antibody cocktail for B cell isolation
    100 µl of MACS buffer containing 3 µg/ml of biotinylated anti-CD43
    2.5 µg/ml of biotinylated anti-Ter119
    1.5 µg/ml of biotinylated anti-CD4
    1.5 µg/ml of biotinylated anti-CD8
    1.5 µg/ml of biotinylated anti-CD49b
    Make the cocktail just before use
    Note: Anti-CD43 antibody can be used for depletion of various immune cells except for B cells, e.g., macrophages, granulocytes, dendritic cells, and T cells. The anti-CD49b antibody recognizes NK and NKT cells. Addition of both antibodies improves the purity of B cells.
  6. Antibody cocktail for feeder cell depletion (for cells from one 10 cm dish)
    260 µl of MACS buffer containing 2.89 µg/ml of biotinylated anti-H-2Kd
    To deplete plasma cells simultaneously, add biotinylated anti-CD138 at 1.15 µg/ml to the cocktail
    Make the cocktail just before use

Acknowledgments

The present protocols are modified from the original version of our article (Nojima et al., 2011). The authors want to thank Dr. Takuya Nojima and Dr. Tatsuya Moutai for their contribution to the development of the iGB culture system. This work was supported by Grant-in-Aid for Scientific Research (B) to D.K.

Competing interests

The authors declare no conflict of interest.

References

  1. Fukao, S., Haniuda, K., Nojima, T., Takai, T. and Kitamura, D. (2014). gp49B-mediated negative regulation of antibody production by memory and marginal zone B cells. J Immunol 193(2): 635-644.
  2. Haniuda, K., Fukao, S., Kodama, T., Hasegawa, H. and Kitamura, D. (2016). Autonomous membrane IgE signaling prevents IgE-memory formation. Nat Immunol 17(9): 1109-1117.
  3. Moutai, T., Yamana, H., Nojima, T. and Kitamura, D. (2014). A novel and effective cancer immunotherapy mouse model using antigen-specific B cells selected in vitro. PLoS One 9(3): e92732.
  4. Nojima, T., Haniuda, K., Moutai, T., Matsudaira, M., Mizokawa, S., Shiratori, I., Azuma, T. and Kitamura, D. (2011). In-vitro derived germinal centre B cells differentially generate memory B or plasma cells in vivo. Nat Commun 2: 465.
  5. Takatsuka, S., Yamada, H., Haniuda, K., Saruwatari, H., Ichihashi, M., Renauld, J. C. and Kitamura, D. (2018). IL-9 receptor signaling in memory B cells regulates humoral recall responses. Nat Immunol 19(9): 1025-1034.
